PRODUCT SPECIFICATIONS
AirLive CoreNVR16 16-Channel Network Video Recorder
The AirLive CoreNVR16 is a standalone H.264 network video recorder for managing up to 16 supported IP cameras. Designed for homes, retail stores and small offices, it provides local monitoring, recording and playback without a dedicated recording PC.
HDMI and VGA outputs support local monitor connections, while Gigabit Ethernet connects the recorder to the surveillance network. Embedded Linux provides the operating platform, with camera configuration and recording management available through the recorder's interface.
Key Features
- Up to 16 IP camera channels.
- H.264 video compression.
- Manufacturer-published monitoring and storage support up to 4 MP, subject to camera profile and firmware.
- HDMI and VGA monitor outputs.
- One Gigabit Ethernet network port.
- Two internal SATA HDD connections and an external eSATA interface.
- Scheduled and event-triggered recording.
- Two-way audio and supported PTZ camera control.
Recording and Event Management
Configure recording schedules and supported motion, digital-input or event triggers. Camera disconnection and HDD errors can also generate alarms. Available actions depend on the connected camera, configured events and firmware.
Network Connectivity and Camera Power
The recorder connects to IP cameras through the network. Its 16 recording channels are logical camera channels, not 16 physical Ethernet ports. Cameras require their own suitable power supplies or an external PoE switch or injector.
Ideal Applications
- Retail and convenience-store surveillance.
- Small-office IP camera recording.
- Residential monitoring with supported cameras.
- Maintenance or expansion of compatible AirLive surveillance installations.
Compatible Products
Use cameras listed by AirLive for CoreNVR compatibility, with supported firmware and an appropriate H.264 stream configuration. Keep the combined camera bitrate within the recorder's published 80 Mbps throughput specification.
- AirLive SmartCube 300W 3 MP Wireless Cube IP Camera – explicitly listed in AirLive's CoreNVR supported-camera table. The camera must be reachable through the IP network.
- AirLive OD-325HD 1.3 MP Outdoor IP Camera – Camera power must be supplied separately.
Technical Specifications
General
- Brand: AirLive
- Model / SKU: CoreNVR16
- Manufacturer Model Styling: CoreNVR 16
- Product Type: Standalone network video recorder
- Camera Channels: Up to 16
- Operating System: Embedded Linux
Processor
- Processor Platform: ARM Cortex-A9
Video and Audio
- Video Codec: H.264
- Published Monitoring / Storage Resolution: Up to 4 MP; camera and firmware limitations apply
- Published Throughput: 80 Mbps
- Monitor Outputs: 1 x HDMI, 1 x VGA
- Maximum Listed Local Display Resolution: 1920 x 1080
- Audio Input: 1 x 3.5 mm microphone jack
- Audio Output: 1 x 3.5 mm jack
- Audio Codecs: G.711 / G.726
Ethernet and Peripheral Interfaces
- Network: 1 x RJ45, 10/100/1000 Mbps Ethernet
- USB: 2 ports for supported peripherals and storage
- External Storage: 1 x eSATA
- Digital Inputs: 4
- Digital Outputs: 4
- Camera PoE Output: No integrated PoE camera ports
Storage
- Internal HDD Connections: 2 x SATA III
- Published Maximum Drive Capacity: 6 TB per drive; compatibility and firmware verification required
- Nominal Combined Internal Capacity: Up to 12 TB before formatting or storage-configuration overhead
- Backup: USB mass storage
Power
- Recorder Input: 12 V DC; technical specifications list 4 A
- Documented Supplied Adapter: 12 V DC, 5 A in the manufacturer's package-content list
- Adapter AC Input: 100-240 V AC
Physical and Environmental
- Dimensions: 33.3 x 5.7 x 25.2 cm, in the manufacturer's published order
- Operating Temperature: 0°C to 40°C
- Operating Humidity: 10% to 80%
Manufacturer-Listed Package Contents
- CoreNVR16 recorder
- Power adapter
- 2 SATA data cables
- 2 SATA power cables
- 4 hard-disk holders
- Quick installation guide
- Manual disc
