PRODUCT SPECIFICATIONS
H3 - Elegant Hotel IP Phone (Black) (Customizable Name Panel)
The Fanvil H3 IP Phone is specifically designed for hotel environments, offering a perfect blend of style and functionality. Its sleek design, combined with robust features, ensures seamless communication for hotel guests and staff. With its customizable name panel and two color options (black and white), the H3 is an elegant and affordable choice for modern hotel IP telephony.
Fanvil H3 Hotel IP Phone
- Fanvil H3 offers a stylish and modern design, making it a new generation of intelligent terminal equipment for hotels. It not only enhances the room's aesthetics but also delivers excellent voice quality for a premium guest experience
Elegant Outlook
- Fanvil H3 is the IP Phone designed for hotels. With a stylish, fresh appearance, excellent voice quality, and matching integrated communication platform, it can become a new generation of hotel intelligent terminal equipment.
6 Programmable Soft Keys for Service Hotline
- The H3 comes with 6 programmable soft keys, allowing easy access to essential hotel services such as housekeeping, ticketing, switchboard, and more. It also supports features like morning calls and voice messaging, enhancing the overall guest experience.
Support SIP Hotspot
- Fanvil H3 can share a single number across multiple extension phones, ensuring that calls are never missed.
Highlights
- Concise and Fashionable Appearance: Combines modern design with environmental friendliness.
- Easy Installation and Configuration: Quick setup with minimal effort.
- High Interoperability: Compatible with major platforms like 3CX, Broadsoft, Elastix, Asterisk, Xorcom, and more.
- Power over Ethernet (PoE): Supports PoE for easy installation and reduced cabling.
Dimension (L×W×H)
- 151.7x193.2x131.7mm
Technical Description
- Generic: 2 SIP lines, PoE enabled, Handset/Hands-free mode, Intelligent DSS Keys (speed dial key), Desktop, Optional external power supply.
- Call Features: Call hold/resume, call waiting, call transfer, speed dial, intercom, voice messaging, mute, intercom, redial, hot line, hot decking and more.
- Phone Functions
- Call logs with missed calls/ incoming calls/ outgoing calls. Max support 600 records(web)
- Dial without registration
- LED light
- Programmable DSS keys
- Custom LCD text and logo(Only support for H5)
- Action URL / Active URI
- Web dial
- Audio
- Audio CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB, G.722
- Full-duplex Acoustic Echo Canceller (AEC)
- Voice Activity Detection (VAD) / Comfort Noise Generation(CNG) / Background Noise Estimation (BNE) / Noise Reduction(NR)
- Packet Loss Concealment (PLC)
- Dynamic Adaptive Jitter Buffer up to 300ms
- DTMF: In-band, Out-of-Band - DTMF(RFC2833) / SIP INFO
- Network
- 10/100Mbps Ethernet, dual bridged port for PC bypass
- IP Configuration: Static / DHCP / PPPoE
- Network Access Control: 802.1x
- VPN: L2TP / OpenVPN
- VLAN
- QoS
- Protocols
- SIP2.0 over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN
- DHCP
- PPPoE
- 802.1x
- L2TP
- OpenVPN
- SNTP
- FTP/TFTP
- HTTP/HTTPS
- TR-069
- Deployment & Management: Auto-provisioning via FTP/TFTP/HTTP/HTTPS, web management portal, configuration export/import, firmware upgrade, syslog.
- Physical Specifications
- LCD: 3.5 inch (480x320) color screen (H5)
- Keypad: 26 keys, including
- 6 DSS Key
- 4 Function keys (Hold, Call Transfer, Redial, MWI)
- 12 Standard Phone Digits keys
- 3 Volume Control keys, Lower/Increase/Mute (Microphone)
- 1 Hands-free
- HD Handset (RJ9) x1
- Standard RJ9 Handset Wire x1
- 1.5M CAT5 Ethernet Cable x1
- RJ9 Port x1: Handset x1
- RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
- USB Port x1: Standard A, Only used for mobile phone charging
- DC Power Input: 5V / 1A
- Power Consumption: Idle 1.8W~2.5W, Peak 3W~4.5W
- Working Temperature: 0~40℃
- Working Humidity: 10~95%
- Installation: Desktop Stand
- Color: Black
More Information
MFRPartNum:
H3
Datasheet:
