Fanvil SIP Audio Intercom 2 SIP Lines IP65 POE 2DSS Keys HD Audio



Fanvil i16S-02P - SIP Intercom

Fanvil i16S-02P/i16SV-02P SIP Intercom is designed for outdoor scenes with high reliability, HD Audio/Video, and IP65/IK10 protection grade. It combines security, audio/video intercom and broadcasting functionalities and offers the best communication solution for users.


  • Built-in HD camera with infrared night vision, adopted H.264 codec (only i16SV-02P)
  • IP65 is waterproof and dust-proof.
  • IK10 anti-collision with robust die-cast aluminum frame
  • Anti-tamper- alarming as long as the cover is apart from the housing, and reporting to the control center at the same time
  • HD voice speech quality with built-in 3W speaker and Acoustic Echo Canceller
  • Audio line out port, expandable external active speaker.
  • Built-in 2 short-in detection ports and 2 short-out control ports
  • Support built-in TF card slot for data storage or audio offline broadcasting


  • 195x120x40 mm

Technical Description

  • Product code: i16S-02P
    • Generic
      • 2 SIP lines
      • Speed dial
      • Linkage with IP camera to realize video intercom
      • Oral announcement of the IP address(in English)
      • MP3 broadcasting
      • Support programmable DSS key
      • Support mono active speaker
      • Talkback recording output
      • Switch signal input and output
      • Support TF card
      • PoE enabled
    • Device Functions
      • Auto-answering
      • Programmable DSS keys
      • Through button or web page volume adjustment
      • Network time synchronization
      • Time Plan (task management)
      • Incoming call multicast
      • Dynamic multicast function
      • HTTP API
      • Action URL / Active URI
    • Call Functions
      • Call out / answer / reject
      • Call waiting
      • Intercom, Multicast
      • Speed dial
      • Anonymous call (Hide caller ID)
    • Audio
      • Narrowband codec: G.711A/U, G.729A/B, iLBC, G.723, G.726-32K
      • Wideband codec: G.722, Opus
      • Full-duplex hands-free speakerphone with AEC
      • DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
    • Network
      • Physical: 10/100 Mbps Ethernet
      • IP mode:IPv4/IPv6/IPv4&IPv6
      • IP configuration: Static IP / DHCP / PPPoE
      • VPN: L2TP / OpenVPN
      • VLAN
      • LLDP
      • Qos
