PRODUCT SPECIFICATIONS
Intellinet 402446 19-Inch 2U Hinged Wall Bracket
The Intellinet 402446 is a compact wall-mount bracket for shallow 19-inch rackmount equipment and patch panels. Its 2U mounting format provides space for organizing network terminations where a small wall-mounted installation is appropriate.
Each level is individually hinged, allowing access to the rear of installed equipment for cable termination, inspection and maintenance. A rear cable passthrough cutout helps route cabling through the mounting area.
Key Features
- 19-inch mounting format for most standard patch panels.
- 2U total mounting height.
- Individually hinged levels for rear access.
- Manufacturer-specified 5-inch depth for shallow equipment.
- Rear cutout for cable passthrough.
- Black finish.
- Screws included.
Hinged Access for Installation and Maintenance
The hinged design makes rear connections easier to reach during installation and service. Independent movement at each level provides access to the corresponding mounting position.
Wall Mounting and Cable Routing
The bracket mounts shallow rack equipment directly to a wall. Its rear opening provides a cable routing path, helping installers organize incoming wiring around the patching area.
Equipment Selection
Select equipment with a compatible 19-inch mounting format and sufficient clearance for rear terminations, cable bends and hinge movement. Check equipment depth and installation requirements before purchase.
Ideal Applications
- Wall-mounted structured cabling terminations.
- Small office and branch-office patching locations.
- Space-constrained installations using shallow patch panels.
- Network installations requiring convenient rear service access.
Compatible Products
The Intellinet 402446 is designed for most 19-inch patch panels and shallow rackmount equipment. Compatibility requires a suitable mounting pattern, adequate equipment and cable clearance, and a properly supported wall installation.
- Intellinet 519526 Cat6 16-Port 1U Patch Panel – Matches the bracket's intended shallow 19-inch patch-panel format. The manufacturer specifies a 1U height and 48 mm panel depth; allow additional clearance for rear terminations and cable bends.
Technical Specifications
General
- Brand: Intellinet Network Solutions
- Model / MPN: 402446
- Alphanumeric Part Number: IHWB-192U-BK
- Product Type: Hinged wall-mount bracket
- Color: Black
Mounting and Access
- Equipment Mounting Format: 19-inch rackmount
- Mounting Height: 2U
- Intended Equipment: Most 19-inch patch panels and shallow rackmount equipment
- Hinge Arrangement: Each level individually hinged
- Cable Routing: Rear cable passthrough cutout
- Advertised Depth: 5 inches
Physical Specifications
- Overall Dimensions: 148 mm (L) x 487 mm (W) x 89 mm (H)
- Net Weight: 1.44 kg
- Gross Weight: 1.6 kg
Included Hardware and Warranty
- Included Hardware: Screws; quantity and type are not specified in the cited documentation
