PRODUCT SPECIFICATIONS
Iuron IU-CAB-QSFP/4SFP+-P3M Passive Copper Breakout Cable
The Iuron IU-CAB-QSFP/4SFP+-P3M is a passive copper breakout cable that connects one 40G QSFP+ interface to four 10G SFP+ interfaces. This configuration provides connectivity between equipment with a QSFP+ port and devices using multiple SFP+ ports.
The QSFP+ connector is rated for 40 Gb/s, while each of the four SFP+ connectors is rated for 10 Gb/s. The cable supports a channel data rate of up to 10.3125 Gbps and complies with applicable QSFP+ and SFP+ interface specifications.
Key Features
- Passive copper breakout configuration with one QSFP+ connector and four SFP+ connectors
- QSFP+ connector rated for 40GBASE operation
- Four SFP+ connectors rated for 10GBASE operation
- Up to 10.3125 Gbps data rate per channel
- Compliant with SFF-8436, SFF-8431, SFF-8432, and SFF-8472
- Compliant with SFP+ and QSFP MSA requirements
- Single 3.3 V power supply
- RoHS compliant
Applications
- Connections between QSFP+ equipment and multiple SFP+ ports
- Switch, router, and host bus adapter interconnections
- Rack-to-rack and shelf-to-shelf connections
- Enterprise and data center networking and storage environments
Technical Specifications
- Ports / Interfaces
- Connector 1: QSFP+ 40GBASE rated connector, SFF-8436 compliant
- Connector 2: 4 x SFP+ 10GBASE rated connectors, SFF-8431 compliant
- QSFP+ Electrical Interface: 38-pin edge connector
- SFP+ Electrical Interface: 20-pin edge connector
- Management Interface: Serial, I2C
- Networking
- Cable Type: Passive copper breakout cable
- Cable Assembly: 40 Gb/s to 10 Gb/s
- Channel Data Rate: 10.3125 Gbps
- Network Support: 10G/40 Gigabit Ethernet
- Standards Compliance: SFF-8436, SFF-8431, SFF-8432, and SFF-8472
- Power
- Supply Voltage: 3.3 V nominal
- Environmental
- Operating Temperature: 0 to +70°C
- Storage Temperature: -40 to +85°C
- Certifications
- RoHS: Compliant
More Information
MFRPartNum:
IU-CAB-QSFP/4SFP+-P3M
