Part:
AXA-NMNM

L-Com AXA-NMNM Coaxial Barrel Adapter, Type N-Male / Male

$19.95
Condition:
New

PRODUCT SPECIFICATIONS

L-com AXA-NMNM N-Male to N-Male Barrel Adapter

  • Nickel plated body for enhanced corrosion resistance Gold plated center contact for reduced signal loss.

  • Handy device to have on hand to solve your interconnection problems.

  • Impedance 50 Ohms

  • Frequency Range DC ~ 11 GHz

  • Voltage Rating 1500 Volts Peak

  • Dielectic Withstanding Voltage 2500 Volts RMS

  • Insertion Loss .15 dB Max.

  • Mating 5/8-24 UNEF Threaded Coupling

  • Mating Torque 15 inch pounds (170 N.cm) Max.

  • Body Nickel Plated Brass

  • Contact Gold Plated Brass

  • Insulator TFE

  • Temperature Range -55C(-67F) to +85C(+185F)

  • Temperature Cycling MIL-Std. 202 Method 102 (Test Condition C)

  • Weatherproof All N-Type Connectors are Weatherproof

  • Moisture Resistance MIL-Std. 202 Method 106 (Test Condition B)

  • Corrosion MIL-Std. 202 Method 101 (Test Condition C)

  • Vibration MIL-Std. 202 Method 204 (Test Condition B)

  • Altitude MIL-Std. 202 Method 105 (Test Condition C)

  • RoHS Compliant Yes

More Information

MFRPartNum:
AXA-NMNM
