PRODUCT SPECIFICATIONS
L-com CA-RSPNFBCN19 RP-SMA to N-Female Bulkhead Pigtail, 19 Inches
The L-com CA-RSPNFBCN19 is an RF antenna-feed cable for connecting an internal RP-SMA interface to an N-female bulkhead connection. It provides a practical connection point through a suitable equipment enclosure or panel.
This factory-assembled pigtail uses 50-ohm 100-Series coaxial cable and a straight connector at each end.
Key Features
- RP-SMA plug to standard-polarity N-female bulkhead.
- 19-inch nominal length.
- 50-ohm cable and connector interfaces.
- 100-Series low-loss coaxial construction.
- O-ring at the N-female bulkhead for panel sealing.
- Factory-tested assembly.
Connector Configuration
The RP-SMA plug mates with an RP-SMA jack. The N-female bulkhead accepts a matching standard N-male connector. Verify connector polarity and center contacts before installation.
Enclosure Integration
The bulkhead termination allows an external RF connection while keeping the internal cable routed within the enclosure. Confirm panel thickness, mounting clearance, and sealing requirements for the intended installation.
Ideal Applications
- Wireless OEM enclosure assemblies.
- External antenna connections for compatible RF equipment.
- Replacement pigtails where the original assembly requirements match.
Compatible Products
This assembly requires an RP-SMA jack at the plug end and a standard-polarity N-male connection at the bulkhead end. The connected RF system must use compatible 50-ohm interfaces.
Specific equipment models have not been confirmed. Verify the operating frequency, RF power, acceptable insertion loss, mounting dimensions, and environmental requirements before selecting a radio, antenna, or additional cable.
Important: RP-SMA and standard SMA are different interfaces. The N-female bulkhead is standard polarity. Its O-ring does not establish a weatherproof rating for the entire cable or enclosure.
Technical Specifications
General
- Brand: L-com
- Model / MPN: CA-RSPNFBCN19
- Product Type: RF coaxial antenna-feed pigtail
Connectors
- Connector 1: RP-SMA plug, straight
- Connector 1 Polarity: Reverse polarity
- Connector 2: N-female bulkhead, straight
- Connector 2 Polarity: Standard
- Connector Impedance: 50 ohms at both ends
- Bulkhead Seal: O-ring
Cable and Dimensions
- Cable Type: 100-Series low-loss coaxial cable
- Cable Impedance: 50 ohms
- Nominal Length: 19 in (482.6 mm)
- Drawing Length Tolerance: +2 in / -0 in for this length range
- Jacket: Black PVC
- Connector Strain Relief: Black PVC heat shrink
Factory Verification
- Continuity: Testing specified by the engineering drawing
