PRODUCT SPECIFICATIONS
APA-1 - Automotive Power Adapter
The APA-1 is an Automotive Power Adapter designed to protect your LtAP and other devices from aggressive vehicle environments. It features multiple safety mechanisms, including overvoltage protection, ensuring the security of your devices from voltage spikes caused by various vehicle-related issues such as failed car batteries, harness coupling, jump-starting, or AC unit switches.
The APA-1 is designed for both indoor and outdoor use, providing flexible deployment options for various environments. It is E-mark certified and compatible with other E-mark certified devices, ensuring it meets stringent automotive standards.
The APA-1 is compatible with E-mark certified devices like LtAP-2HnD&FG621-EA and RB912R-2nD-Ltm&R11e-LTE, ensuring reliable performance and protection in automotive applications. This robust power adapter is designed to maintain device functionality and prevent damage from unexpected electrical conditions, making it an essential accessory for automotive and mobile applications.
Key Features
- Gas-Discharge Tube: Provides a low-resistance path for excess voltage by ionizing gas within a tiny glass tube, protecting devices from voltage spikes.
- Transient Voltage Suppressor (TVS): A semiconductor that safeguards against extreme voltage spikes.
- Active Polarity Protection: Ensures devices remain safe even if power is applied in reverse.
- Low-Pass Filter: Blocks unwanted impulses to protect connected devices.
- Standard Fuse: Provides additional protection against electrical faults.
- Adjustable Output Voltage: Easily modified via jumper position, with a pass-through mode available for input voltage regulation.
Highlights
- Versatile Deployment: Can be used with the GPER IP67 case for additional protection.
- Gas-Discharge Tube: Ensures protection from high voltage by providing a low-resistance path.
- TVS Protection: Protects devices from voltage spikes.
- Active Polarity Protection: Keeps devices safe even if power is applied incorrectly.
- Low-Pass Filter and Standard Fuse: Additional layers of protection.
- Adjustable Output Voltage: Customizable to meet specific needs.
Technical Description
- Product Code: APA-1
- Number of DC Inputs: 1 (3-pin terminal)
- Minimum Voltage: 12 V
- Maximum Voltage: 48 V
- Maximum Power Consumption: 100 W
- Dimensions: 86 x 16 x 31 mm
- Can be used indoors: Yes
- Can be used outdoors: Yes
- Operating Temperature: -40°C to +85°C
- Certifications: CE, E-MARK, EAC, ROHS
- Cooling Type: Passive
- IP Rating: IP20
- Certified: APA-1 is E-mark certified and compatible with other E-mark certified devices: LtAP-2HnD&FG621-EA RB912R-2nD-Ltm&R11e-LTE
