PRODUCT SPECIFICATIONS
Model: CRS309-1G-8S+IN
Mikrotik CRS309-1G-8S+IN Desktop Switch 1-Port Gigabit Ethernet and 8-Port SFP+ 10Gbps
The CRS309-1G-8S+ is a very compact, yet powerful networking switch. It has eight SFP+ slots, supporting up to 10 Gbit module in each, which results in a total switching capacity of 162 Gbps and total non-blocking throughput of 81 Gbps.
The device also has dual-core 800 MHz CPU, 512 MB RAM, a management Ethernet port with PoE power input, RS232 serial port, a grounding terminal and is capable of dual boot (choose which operating system you prefer, RouterOS, or SwOS).
Technical Description
- Specifications
- Product code: CRS309-1G-8S+IN
- Architecture: ARM 32bit
- CPU: 98DX8208
- CPU core count: 2
- CPU nominal frequency: 800 MHz
- Dimensions: 272 x 158 x 44 mm
- License level: 5
- Operating System: RouterOS / SwitchOS
- Size of RAM: 512 MB
- Storage size: 16 MB
- Storage type: FLASH
- Tested ambient temperature: -40°C to 70°C
- Powering
- PoE in: 802.3af/at
- PoE in input Voltage: 18-57 V
- Number of DC inputs: 2 (DC jack, PoE-IN)
- DC jack input Voltage: 12-57 V
- Max power consumption: 23 W
- Max power consumption without attachments: 17 W
- Ethernet
- 10/100/1000 Ethernet ports: 1
- Fiber
- SFP+ ports: 8
- Peripherals
- Serial port: RS232
- Other
- CPU temperature monitor: Yes
More Information
MFRPartNum:
CRS309-1G-8S+IN
Datasheet:
