PRODUCT SPECIFICATIONS
SKU: RB952Ui-5ac2nD-TC-US - hAP ac lite TC
The hAP ac lite is a Dual-concurrent Access Point, that provides WiFi coverage for 2.4GHz and 5GHz frequencies at the same time.
Unit is equipped with a 650MHz CPU, 64MB RAM, five 10/100Mbps Ethernet ports (PoE output on port #5), dual-chain 802.11b/g/n 2.4GHz wireless, single chain 802.11a/n/ac 5GHz wireless, USB port for 3G/4G modem and a RouterOS L4 license.
New design universal case allows unit to be positioned either horizontally (desktop) or vertically (tower case). Wall anchored mounting kit is provided.
RB952Ui-5ac2nD-TC (International) supports 2412-2484MHz and 5150MHz-5875MHz range (Specific frequency range can be limited by country regulations).
RB952Ui-5ac2nD-TC-US (USA) is factory locked for 2412-2462MHz, 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
Technical Description
- Specifications
- Product code: RB952Ui-5ac2nD-TC
- Architecture: MIPSBE
- CPU: QCA9531
- CPU core count: 1
- CPU nominal frequency: 650 MHz
- Switch chip model: QCA9531
- Dimensions: 34 x 119 x 98mm
- RouterOS license: 4
- Operating System: RouterOS
- Size of RAM: 64 MB
- Storage size: 16 MB
- Storage type: FLASH
- MTBF: Approximately 100'000 hours at 25C
- Tested ambient temperature: -30°C to 70°C
- Wireless capabilities
- Wireless 2.4 GHz Max data rate: 300 Mbit/s
- Wireless 2.4 GHz number of chains; 2
- Wireless 2.4 GHz standards: 802.11b/g/n
- Antenna gain dBi for 2.4 GHz: 1.5
- Wireless 2.4 GHz chip model: QCA9531
- Wireless 2.4 GHz generation: Wi-Fi 4
- Wireless 5 GHz Max data rate: 433 Mbit/s
- Wireless 5 GHz number of chains: 1
- Wireless 5 GHz standards: 802.11a/n/ac
- Antenna gain dBi for 5 GHz: 2
- Wireless 5 GHz chip model: QCA9887
- Wireless 5 GHz generation: Wi-Fi 5
- WiFi speed: AC750
- Ethernet
- 10/100 Ethernet ports: 5
- Peripherals
- Number of USB ports: 1
- USB Power Reset; Yes
- USB slot type: USB type A
- Max USB current (A): 1
- Powering
- Number of DC inputs: 2 (PoE-IN, DC jack)
- DC jack input Voltage: 10-28 V
- Max power consumption: 20 W
- Max power consumption without attachments: 8 W
- Cooling type: Passive
- PoE in: Passive PoE
- PoE in input Voltage: 10-28 V
- PoE-out
- PoE-out ports: Ether5
- PoE out: Passive PoE
- Max out per port output (input 18-30 V): 500 mA
- Max total out (A): 500 mA
