Part:
RBD22UGS-5HPacD2HnD-15S-US

Mikrotik mANTBox 52 15s Dual-Band 2.4/5 GHz Gigabit Base Station w/ Sector Antenna (US Version)

$159.00

PRODUCT SPECIFICATIONS

SKU: RBD22UGS-5HPacD2HnD-15S-US

Mikrotik mANTBox 52 15s - RBD22UGS-5HPacD2HnD-15S (US Version)

Are you managing an outdoor wireless network with a variety of access points and CPE devices? Then our brand new mANTBox 52 15s has got you covered – offering powerful built-in antennas, fascinating connectivity options and more!

Creating an efficient point-to-multipoint connection used to be tricky, but not anymore: mANTBox 52 15s works well in any setup. The dual-band wireless capability allows you to use both 2.4 GHz and 5 GHz devices at the same time. There is a Gigabit Ethernet port and an SFP port for fiber connections.

We have doubled the RAM and added a new quad-core CPU that can handle even the heaviest loads. mANTBox 52 15s can even provide IPsec hardware offloading without trouble. Depending on the rest of your setup, you can reach distance up to 20 km with the built-in dual polarization antenna.

mANTBox package includes everything you need: a Gigabit PoE injector, a power supply, a hose clamp and a fastening set, and the MikroTik quickMOUNT pro. This advanced wall mount adapter allows turning antenna within 140° both horizontally and vertically. With the quickMOUNT pro it is possible to perfectly set antenna alignment using an integrated graduated scale.

Specifications

  • Product code    RBD22UGS-5HPacD2HnD-15S
  • Architecture    ARM 32bit
  • CPU    IPQ-4019
  • CPU core count    4
  • Dimensions    140 x 348 x 82 mm
  • RouterOS license    4
  • Operating System    RouterOS
  • Size of RAM    256 MB
  • Storage size    16 MB
  • Storage type    FLASH
  • MTBF    Approximately 200'000 hours at 25C
  • Tested ambient temperature    -40°C to +70°C
  • IPsec hardware acceleration    Yes

Powering

  • Number of DC inputs    2 (DC jack, PoE-IN)
  • DC jack input Voltage    12-57 V
  • FAN count    Passive
  • PoE in    802.3af/at
  • PoE in input Voltage    12-57 V

Wireless specifications

  • Wireless 2.4 GHz Max data rate    300 Mbit/s
  • Wireless 2.4 GHz number of chains    2
  • Wireless 2.4 GHz standards    802.11b/g/n
  • Antenna gain dBi for 2.4 GHz    12
  • Wireless 2.4 GHz chip model    IPQ-4019
  • Wireless 2.4 GHz generation    Wi-Fi 4
  • Wireless 5 GHz Max data rate    867 Mbit/s
  • Wireless 5 GHz number of chains    2
  • Wireless 5 GHz standards    802.11a/n/ac
  • Antenna gain dBi for 5 GHz    15
  • Wireless 5 GHz chip model    IPQ-4019
  • Wireless 5 GHz generation    Wi-Fi 5

Ethernet

  • 10/100/1000 Ethernet ports    1

Fiber

  • SFP ports    1

Peripherals

  • Number of USB ports    1
  • USB slot type    USB type A
  • Max USB current (A)    1

Other

  • PCB temperature monitor    Yes
  • Voltage Monitor    Yes

Certification & Approvals

  • Certification    CE, FCC, IC, EAC, ROHS
  • IP    IP55

More Information

MFRPartNum:
RBD22UGS-5HPacD2HnD-15S-US
Datasheet:
