MikroTik RBLDF-5nD-US LDF 5GHz Outdoor Wireless CPE Dish Feed Antenna Passive PoE Long Range Link

The LDF (Lite Dish Feed) is an outdoor wireless system with a built in antenna, meant to be installed on satellite offset dish antennas. The dish will act as a reflector, amplifying the signal. This means you can use any available satellite TV dish with an offset mount to quickly deploy powerful long range wireless links. The offset mount is universal at 40 mm diameter, and the LDF can easily be placed inside it. Since the LDF itself is a tiny little package, it makes shipping and deployment simple and low cost. LDF 5 ac is equipped with a Gigabit port and supports 802.11ac for higher throughput.

Key Features

• IP 54
• Outdoors
• PoE

Technical Specification

• Specifications:
  • Architecture: MIPSBE
    CPU: AR9344
    CPU core count: 1
    CPU nominal frequency: 600 MHz
    Dimensions: 84x84x115mm
    RouterOS license: 3
    Operating System: RouterOS
    Size of RAM: 64 MB
    Storage size: 16 MB
    Storage type: FLASH
    MTBF: Approximately 100'000 hours at 25C
    Tested ambient temperature: -40°C to 70°C
• Powering:
  • Number of DC inputs: 1 (PoE-IN)
  • Max power consumption: 6 W
  • PoE in: Passive PoE
  • Cooling type: Passive
  • PoE in input Voltage: 10-30 V
• Wireless specifications:
  • Wireless 5 GHz Max data rate: 300 Mbit/s
  • Wireless 5 GHz Number of chains: 2
  • Wireless 5 GHz standards: 802.11a/n
  • Antenna gain dBi for 5 GHz: 9
  • Wireless 5 GHz chip model: AR9344
  • Wireless 5 GHz generation: Wi-Fi 4
• Ethernet:
  • 10/100 Ethernet ports: 1
• Certification & Approvals:
  • Certification: CE, FCC, IC, EAC, ROHS
  • IP: IP54
