PRODUCT SPECIFICATIONS
The LHG LTE kit is a device for remote locations that are within cellular network coverage. Mount it outdoors, on a pole, mast or any high enough structure, and connect even where cell phones can’t. Due to it’s large sized high gain antenna, the device is capable to connect to cell towers in extreme rural locations, giving you the ability to provide last mile internet access where nothing else is available.
The unit is equipped with one Ethernet port, has a built in high quality Category 4 modem for speeds of up to 150 Mbit/s downlink and 50 Mbit/s uplink.
RBLHGR&R11e-LTE-US includes LTE modem that supports LTE bands 2, 4, 5 and 12, mostly used by mobile operators in United States, Canada and Latin America.
Technical Description
- Specifications
- Product code: RBLHGR&R11e-LTE
- Architecture: MIPSBE
- CPU: QCA9531
- CPU core count: 1
- CPU nominal frequency: 650 MHz
- Dimensions: 391 x 391 x 227 mm
- RouterOS license: 3
- Operating System: RouterOS
- Size of RAM: 64 MB
- Storage size: 16 MB
- Storage type: FLASH
- MTBF: Approximately 200'000 hours at 25C
- Tested ambient temperature: -40°C to 50°C
- Powering
- Number of DC inputs: 1 (PoE-IN)
- Max power consumption: 6 W
- Cooling type: Passive
- PoE in: 802.3af/at
- PoE in input Voltage: 12-57 V
- Mobile
- LTE category: 4 (150Mbps Downlink, 50Mbps Uplink)
- LTE (FDD) bands: 2(1900)/4(1700)/5(850)/12(700)
- 3G category: R8 (Cat24 - 42.2Mbps Downlink) R7 (Cat14 - 21.1Mbps Downlink)
- 3G bands: 2(1900)/5(850)
- Ethernet
- 10/100 Ethernet ports: 1
- Peripherals
- Number of SIM slots: 1 Modem (Micro SIM)
- MiniPCI-e slots: 1
- Other
- Mode button: Yes
- Certification & Approvals
- Certification: CE, EAC, ROHS
- IP: IP54
More Information
MFRPartNum:
RBLHGR&R11e-LTE-US
Datasheet:
