PRODUCT SPECIFICATIONS
Iuron U.FL to Right-Angle RP-SMA Male RG178 Pigtail Cable, 25 cm
The Iuron U.FL-RPSMA.Male.Right-Angle is a 25 cm coaxial RF pigtail with a U.FL connection at one end and a right-angle RP-SMA male connector at the other.
This short interconnect is intended for RF assemblies requiring these specific interfaces. The angled RP-SMA termination changes the cable exit direction, which can help with routing where a straight connector would require additional clearance.
Key Features
- Exact model: U.FL-RPSMA.Male.Right-Angle.
- U.FL connector at one end.
- Right-angle RP-SMA male connector at the other end.
- RG178 coaxial cable, as listed by Flytec.
- 25 cm cable length.
- Short RF interconnect for installations with verified compatibility.
Connector Configuration
The RP-SMA end is identified as male and right-angle. RP-SMA is a reverse-polarity interface and must be distinguished from standard SMA. Check the connector body, threads, and center contact before selecting a mating component.
The miniature end is listed as U.FL. Confirm the equipment's exact connector series rather than assuming that any small snap-on RF connector will fit.
Cable Routing
The 25 cm length suits short interconnections where the equipment layout accommodates the cable and angled termination. Allow adequate clearance and avoid pulling, twisting, or sharply bending the cable at either connector.
RF Selection Requirements
Connector fit alone does not establish electrical compatibility. Confirm operating frequency, impedance, allowable signal loss, and RF power requirements before installation.
Ideal Applications
- Short RF interconnections requiring U.FL and right-angle RP-SMA male interfaces.
- Replacement work where the original cable specifications match this assembly.
- Equipment assembly and repair with documented connector and RF requirements.
Compatible Products
This pigtail should be selected only for equipment with a confirmed mating U.FL interface and a confirmed mating RP-SMA female interface, with sufficient mechanical clearance for the right-angle connector.
- U.FL interface: Verify the exact mating connector series and equipment hardware revision.
- RP-SMA interface: Verify the mating female connector, including its threads and center contact.
- Electrical requirements: Confirm frequency range, impedance, insertion loss, and RF power ratings for the complete assembly.
- Mechanical requirements: Confirm the 25 cm length, connector clearance, and cable routing.
Important: Do not substitute this cable for an RP-SMA female, standard SMA, MMCX, W.FL, or MHF4 assembly based on appearance. Generic descriptions such as 'IPX' or 'IPEX' are insufficient to establish the required connector match.
Technical Specifications
General
- Product Brand: Iuron
- Model / Listed MPN: U.FL-RPSMA.Male.Right-Angle
- Product Type: Coaxial RF pigtail cable assembly
- Flytec Brand-Category Label: PYP Electronic
Cable
- Cable Type: RG178
- Length: 25 cm
Connectors
- Connector A: U.FL, as listed by Flytec
- Connector B: RP-SMA male
- Connector B Orientation: Right-angle
Included Parts
- Listed pigtail cable assembly
- Additional adapters or mounting hardware are not confirmed as included
