PRODUCT SPECIFICATIONS
The unique POE-INJ-LED-S has power on and current indicator LED’s. The Power LED shows that DC power (12V to 24V) is being supplied to the inserter through the DC jack. The Current LED shows that a PoE device is plugged in at the end of the CAT5 Ethernet cable up to 100m (330ft) away from the inserter.
Features
- Shielded CAT5e cable and connectors for added protection against surges and interference
- Cat5 rated RJ45 jack for more reliable high speed data connections (10/100MB)
- Shrouded DC jack for improved safety
Applications
- Wireless Access Points and Client Devices
- IP Phone and Security Camera Systems
Cable Length
- 165mm (6.5”)
Total Length
- 254mm (10”)
Weight
- 31 g (1.1 oz )
Technical Description
- Materials: UL Rated Materials, Meets RoHS Requirements
- Voltage Rating: 60VDC Maximum
- RJ45 Jack: Shielded CAT5 Rated, Gold Plated Contacts
- RJ45 Power: Pins 4,5(+) 7,8(-)
- DC Jack or Plug: 5.5 x 2.1mm, Shrouded
- DC Wire Size: 28AWG x 4
- CAT5 Wire Size: 24AWG x 8, Shielded
- Operating Temp: -40°C to 80°C (-40°F to 176°F)
More Information
MFRPartNum:
POE-INJ-LED-S
