Tycon Power Systems

Part:
TP-SC-BT1

Tycon Bluetooth Adapter For Cream Colored 20/40/60A MPPT Solar Charge Controller

$37.95
$39.95
Condition:
New

PRODUCT SPECIFICATIONS

The Tycon Solar TP-SC-BT1 Bluetooth adapters that connect to the TP-SCxxxx-MPPT solar charge controllers via the RS232 interface on the charge controller. It allows connection to the controllers via a smartphone. This allows a technician to monitor and control the charge controller from a distance of up to 15m. An Android and IOS Mobile app is available to provide the connectivity. There is no external power source required because the Bluetooth Adapter gets it’s power from the RS232 interface on the solar controller.

They operate over a wide industrial temperature range. Electronics are conformal coated for environmental protection.

The units are fully sealed and weatherproof so they are designed to be mounted outdoors.

Features

  • Provides Connectivity up to 15m range
  • Designed for Tycon TP-SC MPPT Charge Controllers
  • Employs a dedicated Bluetooth chip with high performance and ultra low power consumption
  • Adopts Bluetooth 4.0 and BLE technologies; boasting advantages of quick communication, excellent anti-interference capability, etc.
  • No External Power Source Required
  • Conformal Coated Electronics for Environmental Protection
  • Waterproof, Industrial Temperature Range Applications
  • Tycon TP-SCxxxx-MPPT Solar Charge Controllers
  • Remote monitoring and control

Applications

  • Tycon TP-SCxxxx-MPPT Solar Charge Controllers
  • Remote monitoring and control

Dimensions

  • 66 x 51 x 15.5mm (2.6 x 2 x 0.6”)

Weight

  • 120g (4.2oz )

Technical Description

  • Input Voltage: 5V to 12V
  • Standby Power Consumption: 0.04W
  • Operating Power Consumption: 0.05W
  • Communication DIstance: <15m (49’)
  • LED Function: Red Flashing = Data Active ; Off = Standby mode
  • Serial Baud Rate: 9600bps (Fixed)
  • Communication Mode: RS232
  • Connector Type: RJ12
  • Cable Length: 5m (16ft)
  • Environmental Protection: IP67
  • Certifications: CE, RoHS
  • Operating Temp: -40°C to 75°C (-40°F to 167°F)

More Information

MFRPartNum:
TP-SC-BT1
Datasheet:
