PRODUCT SPECIFICATIONS
The Network Video Recorder Pro UNVR Pro is a business-grade network video recorder that provides data redundancy and long-term storage capabilities up to 60 days of storage for 20 4K cameras or 60 1080p cameras.
A 2U-sized video recorder with (7) 2.5/3.5" HDD bays that can provide up to 60 days of storage for (20) 4K cameras or (60) Full HD cameras.
Stack multiple UNVR Pros* to increase your storage capacity and accommodate large security camera systems.
Features:
- (1) 10G SFP+ port
- (1) GbE RJ45 port
- 1.3" touchscreen for video previewing
- Automatic HDD RAID configuration for data redundancy
- Connects to a Power Backup for enhanced power redundancy
Hardware
- Max. Power Consumption
- 160W
- Max. Power Budget for Drives
- 135W
- Power Method
- (1) Universal AC input, 100-240VAC, 3A Max, 50/60 Hz
- (1) USP-RPS DC input, 11.5VDC, 13.91A
- Power Supply
- AC/DC, Internal, 200W
- Networking Interfaces
- (1) 10/100/1000 Mbps RJ45 Ethernet
- (1) 1/10 Gbps SFP+ Ethernet
- RF Interface
- (1) Bluetooth v4.1
- LCM Display
- (1) 1.3" Touchscreen
- Bootup Animation:
- Bootup in Progress
- Firmware Upgrade Icon:
- Firmware Upgrading
- Steady White:
- Factory Defaults, Awaiting Adoption
- Steady Blue:
- Device is Adopted
- Management Interface
- Ethernet In-Band Management
- ESD/EMP Protection
- Air: ± 12kV, Contact: ± 8kV
- Operating Temperature
- -5 to 40° C (23 to 104° F)
- Operating Humidity
- 5 - 95% Noncondensing
- Certifications
- FCC, CE, IC
LEDs
- Ethernet
- White: 10/100/1000 Mbps
- SFP+
- White: 1/10 Gbps
- HDD
- Amber: Disk Error, White: Disk Detected
- RPS
- Blue: Ready
Mechanical
- Dimensions
- 442 x 325 x 87 mm (17.4 x 12.8 x 3.4")
- Weight
- Without Rackmount Brackets: 9.2 kg (20.28 lb)
- With Rackmount Brackets: 9.45 kg (20.83 lb)
- Enclosure Material
- SGCC Steel
- Mount Materials
- SGCC Steel
More Information
MFRPartNum:
UNVR-Pro
Datasheet:
