PRODUCT SPECIFICATIONS
SKU: ACB-ISP - airCube ISP AP
With a compact design and integrated 24V PoE passthrough, airCube ISP is a low-cost home WiFi access point made to interoperate with airMAX CPE devices, with remote management by UISP.
Features
- 802.11n 2x2
- Integrated 24V PoE passthrough
- UISP support for remote network management
Dimensions
- 87.8 x 89.5 x 89.25 mm (3.46 x 3.52 x 3.51")
Weight
- 280 g (9.88 oz)
Compatibilities
- US version
Technical Description
- Hardware
- Networking interface: 10/100 Fast Ethernet ports
- Management interface: WiFi / Ethernet
- Power Method: Micro-USB adapter (not included)
- PoE 24V In on LAN Port 1
- Power supply: 5V
- Max. power consumption: 5W
- Supported power voltage: 4.95—5.05V
- PoE Out: Controllable 24V PoE Out (4, 5+, 7, 8-) on WAN port
- Operating frequency: 2.4 GHz
- Antenna gain: 4 dBi
- Max. speeds: 300 Mbps
- Max. TX power: 20 dBm
- ESD/EMP protection: ± 24 kV RJ45 interface
- LED: Status
- Operating temperature: -10 to 50° C (14 to 122° F)
- Operating humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
More Information
MFRPartNum:
ACB-ISP
Datasheet:
