PRODUCT SPECIFICATIONS
Ubiquiti LBE-5AC-XR airMAX LiteBeam 5AC Extreme-Range
Ultra-lightweight, outdoor, wireless station designed to create extremely long-distance links.
Key Features:
- 5 GHz, 30+ km link range
- 450+ Mbps throughput
- Easy to assemble
Technical Description:
- Mechanical:
- Dimensions: 747 x 525 x 347 mm (29.4 x 20.7 x 13.7')
- Weight: 3.2 kg (7.1 lb)
- Enclosure material: Aluminum alloy, UV stabilized polycarbonate
- Mount material: UV stabilized polycarbonate
- Mounting: Integrated pole mount (included)
- Pole compatibility: Ø35 to 60 mm (Ø1.38 to 2.36')
- Wind loading: 1100 N at 200 km/h (247.29 lbf at 125 mph)
- Weatherproofing: IPX6
- Hardware:
- Networking interface: (1) GbE RJ45 port
- Power method: Passive PoE 2-pair (4, 5+; 7, 8- return)
- Power supply: 24V DC, 0.5A gigabit PoE adapter (Included)
- Supported voltage range: 22—27V DC
- Max. power consumption: 7W
- RF connections: Internal
- LEDs: Power/ethernet
- Button: Factory reset
- Ambient operating temperature: -40 to 70° C (-40 to 158° F)
- Ambient operating humidity: 5 to 95% non-condensing
- Certifications: FCC, IC, CE
- System:
- Maximum throughput: 450+ Mbps
- Encryption: WPA2-PSK (AES)
- Software:
- Modes: PtMP, PtP
- Services: SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog
- Utilities: airView®, speed test, alignment, discovery, ping, traceroute, constellation
- Management interface: Dedicated management radio for quick device setup via the UISP™ Mobile app WEB UI
- Minimum software requirements: Modern Web browser or Android/iOS smartphone
- RF:
- Operating frequency: 5.15 to 5.85 GHz
- Max. conducted TX power: 25 dBm
- Management radio: 2400 - 2483.5 MHz
- Channel bandwidth: 10/20/30/40/50/60/80 MHz
- Antenna Gain: 29 dBi
- Isolation: 20 dB
- Beamwidth:
- HPOL: 3 dB: 5.5°, 6 dB: 7.5°
- VPOL: 3 dB: 5.5°, 6 dB: 7.5°
- Elevation: 3 dB: 5.5°, 6 dB: 7.5°
- Electrical downtilt: 0°
More Information
MFRPartNum:
LBE-5AC-XR
