PRODUCT SPECIFICATIONS
The U-Cable-C6-CMP is a Category 6 UTP cable that supports speeds up to 1Gbps with its 23 AWG solid copper, twisted pair conductor. The conductor's small diameter, combined with the cable's anti-crosstalk divider, isolates and protects signals from interference. The U-Cable-C6 is also a CMP cable with a fire-resistant jacket that ensures full fire prevention, which is especially critical in plenum spaces where air is circulated to facilitate building HVAC. Category 6 Ethernet connectors are recommended to accommodate the conductor's size and optimize its performance.
Features:
- Category 6 Unshielded Twisted Pair (UTP) cable
- Communications Multipurpose Cable, Plenum (CMP)-rated, fire-resistant jacket
- 1,000 ft (305 m)
- 23 AWG solid copper conductor pair
- Anti-crosstalk divider
- For 1000BASE-T Ethernet applications
Technical Description
- Cable Length : 305 m (1000 ft)
- Cable Color: White
- Cable Type: Category 6
- Shielding Type: UTP
- Flame Rating: CMP
- Conductor Wire Gauge: 23 AWG
- Conductor Type: Solid Bare Copper
- Jacket Material: Low Smoke Flame Retardant PVC
- Jacket Diameter: 5.6 ± 0.2 mm
- Bend Radius: Min. 22.4 mm
- Pulling Tension: Max. 110 N
- Storage Temperature: -20 to 75°C (-4 to 167°F)
- Installation Temperature: 0 to 60°C (32 to 140°F)
- Operation Temperature: -20 to 60°C (-4 to 60°F)
- Anti-Crosstalk Divider: Yes
- Ripcord: Yes
- Data Rate: 10/100/1000 Base-T
- Reference Bandwith: Up to 600 MHz
More Information
MFRPartNum:
U-Cable-C6-CMP
