PRODUCT SPECIFICATIONS
Ubiquiti U7-Pro-XG-Wall UniFi WiFi 7 Wall Access Point
The Ubiquiti U7-Pro-XG-Wall is a wall-mounted UniFi WiFi 7 access point with 6 GHz-ready wireless performance and 1/2.5/5/10 GbE support. It supports 6 spatial streams, up to 140 m² (1,500 ft²) of coverage, and 300+ clients for high-capacity UniFi wireless deployments.
Designed for wall mounting, the U7 Pro XG Wall uses a single 10 GbE RJ45 networking interface and is powered by PoE+. It is managed through UniFi Network version 10.0 and later, with supported mobile app management for iOS and Android.
WiFi 7 Performance
The U7 Pro XG Wall supports WiFi 7 with 2 x 2 DL/UL MU-MIMO on the 6 GHz, 5 GHz, and 2.4 GHz bands. Maximum data rates are listed by Ubiquiti as 5.8 Gbps on 6 GHz, 4.3 Gbps on 5 GHz, and 688 Mbps on 2.4 GHz.
Key Features
- Wall-mounted UniFi WiFi 7 access point
- 6 GHz-ready wireless operation
- 6 spatial streams
- 10 GbE uplink with 1/2.5/5/10 GbE support
- PoE+ power method
- Supports 300+ clients
- Coverage area of 140 m² (1,500 ft²)
- Managed through UniFi Network version 10.0 and later
Applications
- Wall-mounted UniFi wireless deployments
- WiFi 7 upgrades using 6 GHz, 5 GHz, and 2.4 GHz bands
- High-client-count wireless networks supporting 300+ clients
- Multi-gigabit wireless access using a 10 GbE uplink
- Guest WiFi deployments using captive hotspot portal features
Technical Specifications
- Capacity
- Spatial Streams: 6
- Coverage Area: 140 m² (1,500 ft²)
- Max. Client Count: 300+
- Ports / Interfaces
- Uplink: 10 GbE
- Networking Interface: (1) 10 GbE RJ45 port
- Management: Ethernet
- LEDs: System
- Wireless
- WiFi Standard: WiFi 7
- MIMO: 6 GHz: 2 x 2 (DL/UL MU-MIMO); 5 GHz: 2 x 2 (DL/UL MU-MIMO); 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
- Max. Data Rate: 6 GHz: 5.8 Gbps (BW320); 5 GHz: 4.3 Gbps (BW240); 2.4 GHz: 688 Mbps (BW40)
- Antenna Gain: 6 GHz: 6 dBi; 5 GHz: 6 dBi; 2.4 GHz: 4 dBi
- Max. TX Power: 6 GHz: 24 dBm; 5 GHz: 26 dBm; 2.4 GHz: 23 dBm
- Max. BSSIDs: 8 per Radio
- Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
- Security
- Guest Network Isolation: Supported
- Private Pre-Shared Key (PPSK): Supported
- Client Device Isolation: Supported
- RADIUS over TLS (RadSec): Supported
- Dynamic RADIUS-assigned VLAN: Supported
- Networking
- Wireless Meshing: Supported
- Band Steering: Supported
- 802.11v BSS Transition Management: Supported
- 802.11r Fast Roaming: Supported
- 802.11k Radio Resource Management (RRM): Supported
- Advanced Radio Management: Supported
- Passpoint (Hotspot 2.0): Supported
- WiFi Speed Limiting: Supported
- WiFi Schedules: Supported
- Hardware
- Enclosure Material: Polycarbonate, aluminum alloy
- Mount Material: Aluminum alloy
- NDAA Compliant: Supported
- Power
- Power Method: PoE+
- Max. Power Consumption: 22W
- Supported Voltage Range: 42.5-57V DC
- Physical
- Dimensions: 155 x 108 x 33.5 mm (6.1 x 4.3 x 1.3')
- Weight: 505 g (1.1 lb)
- Mounting: Wall
- Environmental
- Ambient Operating Temperature: -30 to 40° C (-22 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Software
- Application Requirements: UniFi Network version 10.0 and later
- Mobile App: iOS version 10.29.3 and later; Android version 10.31.1 and later
- Captive Hotspot Portal: Custom Branding Landing Page, Voucher Authentication, Payment-Based Authentication, External Portal Server Support, Password Authentication
- Certifications
- Certifications: CE, FCC, IC
