PRODUCT SPECIFICATIONS
Ubiquiti UACC-Cable-DoorLockRelay-2P Door Lock Relay Cable
A 500-foot (152.4 m) spool of one or two-pair, low-voltage cable.
Key Features:
- 1-Pair Relay Cable: Connects an electric/magnetic lock to an Access Hub
- 2-Pair Relay Cable: Connects an electric/magnetic lock and door position sensor to an Access Hub
- 1-Pair Relay Cable
- (2) 18 AWG conductors for an electric/magnetic lock
- 2-Pair Relay Cable:
- (2) 18 AWG conductors for an electric/magnetic lock
- (2) 22 AWG conductors for a door position sensor
- Cable length 152.4 m
- Plenum-rated
- Compatibility: UA-Lock-Magnetic, UA-G2-SK-Pro, UA-Lock-Electric, UA-G2-SK, EAH-8, UA-G3-SK-Pro, UA-Hub-Door, UA-G3-SK, UA-Hub-Gate, UA-Hub-Door-Mini
Technical Description:
- Mechanical
- Weight: 5.6 kg kg (12.3 lb)
- Cable length: 152.4 m (500 ft)
- Jacket OD: 4.5 mm (0.18')
- Jacket material: Thermoplastic elastomer (TPE)
- Jacket color: White
- Conductor wire gauge: 18/22 AWG
- Insulation material: Semi-rigid polyvinyl chloride (SR-PVC)
- Insulation color: black/red (18AWG), amber/white (22AWG)
- Number of conductors: 4
- Conductor material: Solid bare copper
- Max. pull tension: 24.2 kgf
- Min. bend radius: 56 mm (2.2')
- Conductor DCR: 23.2 ohm/km (18AWG), 59.4 ohm/km (22AWG)
- Voltage: 36V DC
- Flame rating: VW-1
- Current rating: 18AWG: 2A for 500 ft length
- Storage temperature: -45 to 65° C (-40 to 149° F)
- Ambient operating temperature: -45 to 65° C (-40 to 149° F)
More Information
MFRPartNum:
UACC-Cable-DoorLockRelay-2P
