PRODUCT SPECIFICATIONS
A WiFi connected chime that can be plugged into a standard wall outlet and paired with UniFi Protect doorbell.
This device is ideal for homes without a wired chime system or one that is incompatible with their Protect doorbell.
Managed with the UniFi Protect application: Version 2.0 and later (web) / 1.6.2 and later (iOS) / 1.6.0 and later (Android)
Technical Description:
System
- Processor: Single/Dual-Core® Xtensa® 32 bit 400MIPS
- Networking interface: WiFi 802.11 b/g/n
- Power method: AC
- Supported voltage range: 100-240V, 50-60 Hz
- Max. power consumption: 3.7W
- Antenna gain: 2 dBi
- ESD/EMP protection: Air: ± 16kV, contact: ± 8kV
- LEDs: (5) White
- Button: Factory reset
- Operating temperature: 0 to 40° C (32 to 104° F)
- Operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
Audio
- Speaker: Yes
- Buzzer: Yes
Mechanical
- Dimensions: Ø62 x 50.6 mm (Ø2.44 x 1.99") (without prong)
- Weight: 127 g (4.48 oz)
- Enclosure materials: Polycarbonate, fabric
More Information
MFRPartNum:
UP-Chime-US
Datasheet:
