PRODUCT SPECIFICATIONS
Redundant UPS Power System 950W backup power unit that provides full redundancy for rack-mounted UniFi devices.
The SmartPower Redundant Power System, model USP-RPS, is a proprietary redundant power system designed to protect up to six SmartPower supported devices from sudden power supply module failure.
The USP-RPS continually monitors all attached devices. In the event of an internal AC/DC power supply failure, failover is automatic so your network continues to operate with no interruption in service. With a 950W DC power budget, the USP-RPS can protect a variety of high-power devices, including PoE switches. An integrated 1.3" color touchscreen LCM displays system information for convenient monitoring.
Features
- 950W total DC power supply
- (6) USP DC ports
- (1) GbE RJ45 port
- 1.3" LCM color touchscreen
Technical Description
- Dimensions: 442.40 x 325.60 x 43.70 mm (17.42 x 12.82 x 1.72")
- Weight: 5.500 kg (12.13 lb)
- With Mount Brackets: 5.590 kg (12.32 lb)
- Interfaces Networking: (1) 10/100/1000 Mbps RJ45 Port
- Management: Ethernet In-Band
- Power Output: (6) RPS DC Ports
- Max. Power Consumption: 995W
- Power Method: (1) Universal AC Input, 100 to 240VAC
- Power Supply:
- Internal 350W AC/DC
- Internal 645W AC/DC
- Supported Voltage Range: 100 - 240VAC
- Display: 1.3" Color Touch Panel
- LED
- System: Status
- RJ45: Link/Activity
- USP RPS: Activity
- ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
- Operating Temperature: -5 to 45° C (23 to 113° F)
- Operating Humidity: 10 to 90% Noncondensing
- Certifications: CE, FCC, IC
- Total Output Power
- 52VDC: 11.54A (600W)
- 11.5VDC: 30.44A (350W)
- Max. Output Power per RPS Port
- 52VDC: 11.54A (600W)
- 11.5VDC: 30.44A (350W)
More Information
MFRPartNum:
USP-RPS
Datasheet:
