PRODUCT SPECIFICATIONS
Ubiquiti USW-Flex-XG High Performance Managed Layer 2 Multi-Gigabit Switch with (1) PoE input and (4) 10GbE Ethernet ports.
A compact, five-port, Layer 2 switch that supports 10GbE speeds and can be powered with PoE or a 5V USB-C adapter*.
Features:
- (1) GbE, 802.3at PoE+ RJ45 input
- (4) 10GbE RJ45 ports
- Compact, slim housing
- Can be powered with a 5V, 5A USB-C adapter*
*Only single-unit packages include the 5V, 5A USB-C power adapter.
Hardware
- Total Non-Blocking Throughput
- 41 Gbps
- Switching Capacity
- 82 Gbps
- Forwarding Rate
- 61.012 Mpps
- Max Power Consumption
- 25W
- Power Method
- (1) 802.3at PoE, 50-57VDC, 25W
- (1) USB Type-C, 5VDC, 5A
- Power Supply
- 802.3at PoE (Pins 1, 2+/3, 6- or 4, 5+/7, 8-)
- AC/DC Power Adapter, 5VDC, 5A, 1.5 m Cord (Included)
- Supported Voltage Range
- 90 to 264VAC (Adapter)
- Management Interface
- Ethernet In-Band
- Networking Interfaces
- (1) 10/100/1000 Mbps RJ45 Ethernet
- (4) 100/1,000/2,500/5,000/10,000 Mbps RJ45 Ethernet
- Services
- SMB Layer 2 Gigabit Ethernet Switch
- ESD/EMP Protection
- Air: ± 16 kV, Contact: ± 12 kV
- Button
- Factory Reset
- Operating Temperature
- -5 to 45° C (23 to 113° F)
- Operating Humidity
- 10 - 90% Noncondensing
- Certifications
- CE, FCC, IC
LEDs
- System
- (1) Power, Blue/White
- Flashing White: Bootup in Progress
- Flashing Blue: Firmware Upgrading
- Steady White: Factory Defaults, Awaiting Adoption
- Steady Blue: Device is Adopted
- Ethernet
- White: Link or Activity
Mechanical
- Dimensions
- 135 x 185 x 32 mm (5.31 x 7.28 x 1.27")
- Weight
- 1.2 kg (2.65 lb)
- Enclosure Material
- Polycarbonate
More Information
MFRPartNum:
USW-Flex-XG
