PRODUCT SPECIFICATIONS
Ubiquiti UVC-AI-PTZ-B
Industrial-grade 4K PoE++ PTZ camera with enhanced AI capabilities, 22x optical zoom, and long-range adaptive IR LED night vision.
Key Features
- Wall, pole mount, desk stand
- Ultra-low latency remote control
- IP66 weatherproof (outdoor exposed)
- SD card slot
- Built-in IR LED illumination and IR cut filter
- 22x optical zoom
- 4k 1/1.8' 8MP image sensor
- Advanced AI Detections and automatic person tracking
- IR LED 100M IR night vision
- Overview:
- Dimensions: 207 x 223.7 x 341.3 mm (8.2 x 8.8 x 13.4')
- IR Night Vision: 100 m (328 ft)
- Zoom Mode: 22x Optical
- Face Recognition: ✓
- License Plate Recognition: ✓
- Smart Detections (People, Vehicles, Animals): ✓
- Resolution: 4K
- Field of View: H: 3 to 64°, V: 2 to 37°
- Pan-Tilt Range:
- Pan: 360° (Endless)
- Tilt: 120°
- Weatherproofing: IP66
- Mounting: Wall, Pole mount, Desk stand (Included)
- Performance:
- Networking Interface: GbE RJ45 port
- Video:
- Image Settings: Color, brightness, sharpness, contrast white balance, exposure control 2DNR, 3DNR, NR by motion masking, text overlay
- Max. Frame Rate: 30 FPS
- Resolution: 8MP 3840 x 2160 (16:9)
- Optics:
- Sensor: 1/1.8' 8MP
- Lens: 22x optical zoom lens
- Night Mode: Built-in IR LED illumination and IR cut filter
- Hardware:
- Max. Power Consumption: 51W
- Supported Voltage Range: 42.5—57V DC
- Power Method: PoE++
- Processor: Quad-core Arm® Cortex®-A53 based chip
- Weight:
- Without mount: 3.8 kg (8.4 lb)
- Wall mount (Pedant): 3 kg (6.6 lb)
- Table stand: 150 g (5.3 oz)
- Pole mount: 320 g (11.3 oz)
- Enclosure Material: Aluminum alloy, polycarbonate
- Mount Material: Powder-coated aluminum alloy
- Expansion Slot: MicroSD card
- Button: (1) Factory-reset
- Ambient Operating Temperature: -40 to 50º C (-40 to 122º F)
- Ambient Operating Humidity: 0 to 90% noncondensing
- NDAA Compliant: ✓
- Certifications: CE, FCC, IC
More Information
MFRPartNum:
UVC-AI-PTZ-B
