PRODUCT SPECIFICATIONS
Ubiquiti UVC-AI-Theta-Audio
Two-way audio module that connects to an AI Theta Hub.
Key Features:
- Built-in microphone and speaker for two-way audio
- Connects to an AI Theta Hub with the included cable
- Includes flush mount for flat ceiling or wall mounting
Technical Specification
- Mechanical:
- Dimensions: Ø61.5 x 39 mm (Ø2.4 x 1.5')
- Weight:
- UVC-AI-Theta-Audio: 65 g (2.3 oz)
- UVC-AI-Theta-Audio Flush Mount: 22 g (0.8 oz)
- Enclosure material: Aluminum alloy, polycarbonate
- Mount material: Polycarbonate
- Cable jacket enclosure dimensions: 28 x 13 x 7.5 mm (1.1 x 0.5 x 0.3')
- Cable jacket enclosure material: PVC
- Cable length: 1 m (3.3 ft)
- Cable diameter: 3.3 mm (0.13')
- Cable jacket material: Woven fabric
- Cable weight: 18 g (0.63 oz)
- Cable connector type: Theta proprietary
- System:
- Max. power consumption: 4.5W
- Power method: USB Type C, 5V DC, 0.9A
- Mounting: Ceiling mount
- Ambient operating temperature: -20 to 40° C (-4 to 104° F)
- Certifications: FCC, IC, CE
- Audio:
- Microphone: Yes (Can be disabled)
- Speaker: Yes
- Software:
- Web application: UniFi Protect: Version 2.7.18 and later
- Mobile app: UniFi Protect: Version 1.11.0 and later
More Information
MFRPartNum:
UVC-AI-Theta-Audio
