PRODUCT SPECIFICATIONS
Ubiquiti UVC-AI-Turret-W
All-weather, vandal-proof 4K PoE+ turret camera with enhanced AI capabilities and IR and visible LEDs for night vision.
Key Features:
- 4K (8MP) video resolution
- Ultra-wide viewing angle (109.9°)
- 40 m (131 ft) IR night vision
- Advanced AI: Face and license plate recognition
- Integrated LED spotlight for color night vision
- Far-field microphone array for two-way audio
- Micro SD card support for edge recording*
- Connect and power using PoE+
- Weatherproof (outdoor exposed)
Technical Description:
- Mechanical:
- Dimensions: Ø118 x 111 mm (Ø4.6 x 4.4')
- Weight: 990 g (2.2 lb)
- Enclosure material: Aluminum alloy, polycarbonate
- Weatherproofing: IP66
- Resistance: IK08
- Cable jacket enclosure dimensions: Ø20 x 70.6 mm (0.8 x 2.8')
- Cable jacket enclosure material: Thermoplastic elastomer, polycarbonate, silicone rubber
- Cable length: 30 cm (1 ft)
- Cable diameter: 4.5 mm (0.2')
- Cable jacket material: Thermoplastic elastomer
- Cable connector type: RJ45
- Optics:
- Sensor: 1/1.8' 8MP
- Lens: Fixed focal length
- View angle:
- H: 109.9°
- V: 56.7°
- D: 134.1°
- Night mode: Built-in IR LED illumination and IR cut filter
- IR distance: 40 m (131 ft)
- Video:
- Resolution: 8MP 3840 x 2160 (16:9)
- Max. frame rate: 30 FPS
- Image settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
- System:
- Processor: Quad-core Arm® Cortex®-A53 based chip
- Networking interface: GbE RJ45 port
- Max. power consumption: 20W
- Power method: PoE+
- Supported voltage range: 42.5–57V DC
- LED:
- R/G/B/W ring
- Floodlight: 400lm
- Button: Factory reset
- Mounting:
- Ceiling, wall (Included)
- Arm, pendant mount, junction box (Optional)
- Ambient operating temperature: -30 to 50º C (-22 to 122º F)
- Ambient operating humidity: 10 to 90% noncondensing
- Certifications: FCC, IC, CE
- Audio:
- Microphone: Yes (Can be disabled)
- Speaker: Yes (Can be disabled)
- 2-way audio: Yes, with noise cancellation
- Software:
- Web application: UniFi Protect
- Mobile app: UniFi Protect iOS™ and Android™
More Information
MFRPartNum:
UVC-AI-Turret-W
