PRODUCT SPECIFICATIONS
UVC-Doorbell-Lite-W
Compact PoE video doorbell with two-way audio and versatile mounting options.
Key Features
- IR LED 5 m (16 ft) IR night vision
- 2K 1/2.7' 5MP image sensor
- Microphone
- Doorbell button
- Weather-resistant IPX5-rated casing
- Reset button
- Overview:
- Dimensions: 137 x 40 x 26.4 mm (5.4 x 1.6 x 1')
- IR Night Vision: 5 m (16 ft)
- Smart Detections (People, Vehicles, Animals): ✓
- Resolution: 5MP
- Field of View: H: 95.8°, V: 131.2°, D: 175.9°
- Audio: Two-way audio
- Weatherproofing: IPX5
- Mounting:
- Wall, 20° wedge (Included)
- Gang box, junction box (Optional)
- Performance:
- Networking Interface: 10/100 MbE port
- Video:
- Image Settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
- Max. Frame Rate: 24 FPS
- Resolution: 5MP 1920 x 2560 (3:4)
- Optics:
- Sensor: 1/2.7' 5MP
- Lens: Fixed focal length
- Night Mode: Built-in IR LED illumination and IR cut filter
- Hardware:
- Max. Power Consumption: 8W
- Supported Voltage Range: 37—57V DC
- Power Method: PoE
- Processor: Dual-core Arm® Cortex®-A7 based chip
- Weight:
- Device: 142 g (5 oz)
- With flat wall mount: 165 g (5.8 oz)
- With 20° wedge mount: 179 g (6.3 oz)
- Enclosure Material: Polycarbonate, metal
- Mount Material: Formed sheet metal
- Button:
- (1) Ring button
- (1) Factory reset
- Ambient Operating Temperature: -30 to 50° C (-22 to 122° F)
- Ambient Operating Humidity: 20 to 90% noncondensing
- NDAA Compliant: ✓
- Certifications: CE, FCC, IC
More Information
MFRPartNum:
UVC-Doorbell-Lite-W
