PRODUCT SPECIFICATIONS
Ubiquiti UVC-G6-Bullet-W
All-weather 4K PoE camera with a 1/1.8' 8MP image sensor, Multi-TOPS AI Engine, and long-range IR night vision.
Key Features
- Weatherproof IP66 rated
- Adjustable, three-axes mount
- Ceiling, wall and junction box mount
- Microphone
- IR LED 30 m (98 ft) IR night vision
- Multi-TOPS AI engine
- 109,9° viewing angle
- 4K 1/1.8' 8MP image sensor
- Light sensor
- PoE RJ45 port
- Reset button
Technical Specifications
- Overview:
- Dimensions:
- Without mount: Ø82 x 88.8 mm (Ø3.2 x 3.5')
- With mount: Ø82 x 153 mm (Ø3.2 x 6')
- IR Night Vision: 30 m (98 ft)
- Face Recognition: ✓
- License Plate Recognition: ✓
- Smart Detections (People, Vehicles, Animals): ✓
- Resolution: 4K
- Field of View: H: 109.9°, V: 56.7°, D: 134.1°
- Audio: Microphone
- Weatherproofing: IP66
- Tamper Resistance: IK04
- Mounting:
- Wall, ceiling, pole mount (Included)
- Junction box, angled base (Optional)
- Dimensions:
- Performance:
- Networking Interface: 10/100 MbE RJ45 port
- Video:
- Image Settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
- Max. Frame Rate: 30 FPS
- Resolution: 8MP 3840 x 2160 (16:9)
- Optics:
- Sensor: 1/1.8” 8MP
- Lens: Fixed focal length
- Night Mode: Built-in IR LED illumination and IR cut filter
- Hardware:
- Max. Power Consumption: 9.9W
- Supported Voltage Range: 37–57V DC
- Power Method: PoE
- Processor: Quad-core Arm® Cortex®-A53 based chip
- Pole Mount Diameter: 1.5–2' (38–50 mm)
- Weight:
- Without mount: 587 g (1.3 lb)
- With mount: 737 g (1.6 lb)
- Enclosure Material: Polycarbonate, aluminum alloy
- Mount Material:
- Wall mount: aluminum alloy, polycarbonate
- Pole mount: aluminum alloy
- Button: (1) Factory-reset
- Ambient Operating Temperature: -20 to 50° C (-4 to 122° F)
- Ambient Operating Humidity: 0 to 90% noncondensing
- Certifications: CE, FCC, IC
- NDAA Compliant: ✓
More Information
MFRPartNum:
UVC-G6-Bullet-W
