PRODUCT SPECIFICATIONS
A compact and powerful UniFi gateway with a full suite of advanced routing and security features.
Features
- Up to 10x routing performance increase over USG (tested with IPS/IDS, QoS, and Smart Queues)
- Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
- (1) GbE WAN port
- (1) GbE LAN port
- Compact footprint
- USB-C powered (adapter included)
- Managed with UniFi Network 8.0.7 and later
Technical Description
- Mechanical
- Dimensions: 98 x 98 x 30 mm (3.9 x 3.9 x 1.2')
- Weight: 320 g (11.3 oz)
- Enclosure material: Polycarbonate
- Hardware
- Processor: Dual-core ARMĀ® CortexĀ®-A53 at 1 GHz
- Memory information: 1 GB DDR3L
- Management interface:
- Ethernet
- Bluetooth 5.1
- Networking interface
- LAN: (1) GbE RJ45 port
- WAN: (1) GbE RJ45 port
- Power method: USB type C (5V/3A)
- Supported voltage range: 100ā240V
- Max. power consumption: 3.83W
- Ambient operating temperature: -10 to 40Ā° C (14 to 104Ā° F)
- Ambient operating humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
- Gateway Features
- Performance:
- WiFi QoS with UniFi APs
- Application, domain, and country-based QoS
- Application and device type identification
- Internet quality and outage reporting
- Next-generation security:
- Application-aware firewall rules
- Signature-based IPS/IDS threat detection
- Content, country, domain, and ad filtering
- VLAN/subnet-based traffic segmentation
- Full stateful firewall
- Advanced networking:
- License-free SD-WAN* (*When paired with a Cloud Key or Official UniFi Hosting.)
- WireGuard, L2TP and OpenVPN server
- OpenVPN client
- OpenVPN and IPsec site-to-site VPN
- One-click Teleport* and Identity Enterprise VPN** (**When paired with a Cloud Key.)
- Policy-based WAN and VPN routing
- DHCP relay
- Customizable DHCP server
- IPv6 ISP support
- Performance:
- Application Requirements
- UniFi Network: Version 8.0.7 and later
More Information
MFRPartNum:
UXG-Lite
