PRODUCT SPECIFICATIONS
Comtrend’s GS-7624 24-Port PoE Smart-Lite Gigabit Ethernet Switch offers the performance of business-class networking in a cost-effective solution. The GS-7624 features effective management such as remote network monitoring, traffic prioritization, and VLAN features. Additionally, the GS-7624 features PoE for the added benefit of powering Wireless Access Points, IP cameras, and VoIP phones. The GS-7624 is ideal for the business looking for simple management in deployments of high bandwidth video and network services.
Key Benefits:
Simplified Troubleshooting with Port-Mirroring
- Sends a copy of all network packets from any selected port(s) to another port so data can be easily analyzed.
Connect Multiple High- Powered Devices
- Supplies up to 30 watts of power per port. The 330 watts total power budget ensures you always have enough power.
Monitor your Network Remotely
- Remotely disable and enable individual ports to reboot your PoE devices.
PoE Auto Detection
- Supply only the required amount of power, and allow more efficient use of power resources.
Hardware:
- 24 x PoE 10/100/1000Mbps Ports
- 4 x SFP 10/100/1000Mbps Ports
- HW Feature:
- IEEE802.3 10BASE-T
- IEEE802.3u 100BASE-TX
- IEEE802.3ab 1000BASE-T
- IEEE802.3az EEE
- IEEE802.3at
- IEEE802.3af
- MAC Address Table: 8K
- Packet Buffer Size: 512KB, Jumbo Frame: 9K
- PoE Power Budget: 330W
- Power Input:
- AC-to-DC Internal Power Adapter
- Input: 100-240V AC
- Output: 53VDC/2.75A
- Dimension:
- 17.36 x 12.20 x 1.73in (WxDxH)
- 441 x 310 x 44mm (WxDxH)
- Temperature:
- Operating: 32~122°F (0~50°C)
- Storage: -40~158°F (-40~70°C)
- Humidity:
- Operating: 10% ~ 90% RH (Non-condensing)
- Storage: 5% ~ 90% RH (Non-condensing)
- HW Reset Button:
- Supports Reset to Default Function
Software Features:
- Port
- Auto Negotiation of Speed and Duplex Modes
- Jumbo Frame Support
- Cable Diagnostics
- Mirror
- Port Mirroring Both on Ingress and Egress Traffic
- VLAN
- 802.1Q VLAN(IEEE 802.1Q Standard)
- Port-Based VLAN
- LACP
- Link Agression
- IEEE802.3ad
- Multicast
- Blocking of Unknown Multicast Traffic
- QoS
- IEEE802.1p-Based QoS
- Port-Based QoS
- Scheduling Method (WFQ, WRR, WRR+WFQ)
- Rate Limitation
- IGMP Snooping:
- Supports IGMPv1 Snooping—RFC 1122, RFC 4541
- Supports IGMPv2 Snooping—RFC 2236, RFC 4541
- Supports IGMPv3 Snooping (Partial)—RFC 3376
- Multicast Groups
- Security
- Broadcast Storm Control
- Loop Detection/ Prevention
- Management
- User Interface (Web-based Management)
- User Account (System Password Protection)
- Firmware Upgrade by Web User Interface
- Configuration Upload/Download by Web User Interface
- PoE
- PoE Power Output On/Off Management
- EMI/Safety:
- Safety
- CE, LVD, FCC
More Information
MFRPartNum:
GS-7624
