Fanvil

Part:
A320

Fanvil A320 Video Phone 20 SIP Lines

$319.49
$319.95
Condition:
New

PRODUCT SPECIFICATIONS

A320 - Android Touch Screen IP Phone

Fanvil A320 is a high-end enterprise IP phone running on Android 9.0. It offers a seamless touch operation experience with 116 DSS keys, a 10.1-inch color touch screen, Wi-Fi, and Bluetooth. This makes daily communication smart and simple. With a built-in adjustable camera and HD handset, it provides excellent audio and video for group conferences. Compatible with SIP protocol, it's perfect for office or management centers, supporting functions like video calls, intercom, and monitoring.

Highlights

  • 10.1-inch touch screen, 112 DSS keys
  • 20 SIP Lines
  • Support 10-way audio conferencing and 3-way video conferencing
  • Built-in adjustable 8 mega-pixel camera with a privacy cover
  • Support HD audio with G.722 and Opus
  • Support video codec H.264, providing premium HD video calls
  • Built in 2.4G/5G Wi-Fi and Bluetooth 5.0
  • Dual Gigabit ports, Integrated PoE

Technical Description

  • Generic
    • 20 SIP Lines
    • HD Voice
    • Support Video Call
    • PoE Enabled
    • 10.1-inch (1280x800) color touch screen
    • Handset / Hands-free / Headset mode
    • Intelligent DSS Keys (virtual buttons)
    • Optional External Power Supply
    • Android 9.0 OS with higher security and better compatibility
    • Built-in applications: Files, Calendar, Gallery, Browser, Email, Calculator, Notepad, Sound Recorder, Clock, Video, Music
    • Secondary development of API
    • Support third-party applications installation
  • Phone Features
    • Remote phonebook (XML/LDAP, 2000 entries)
    • Intelligent search for contacts and call Log
    • Call logs (In/out/missed, 1000 entries)
    • Voice message waiting indication (VMWI) programmable DSS/Soft keys
    • Network time synchronization
    • Built-in Bluetooth 5.0
    • Built-in Wi-Fi
      • 2.4GHz, 802.11 b/g/n
      • 5GHz, 802.11 a/n/ac
    • Action URL / Active URI
    • UaCSTA
    • Audio/Video recording
    • SIP Hotspot
    • Group broadcasting
    • Action plan
    • Group listening
  • Video
    • Video decoding: H.264, H.265(optional)
    • Video call resolution: CIF/VGA/4CIF/720P/1080P
    • Image format: JPEG/PNG/BMP
    • Video format: MP4
    • Bandwidth selection: 64kbps~4Mbps
    • Frame rate selection: 5~30fps
    • Video from remote site can be displayed in full screen
    • Video call
    • Video Preview
    • Camera - 8 mega-pixel (Adjustable Angle) With Mechanical shutter for privacy
  • Audio
    • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
    • HAC handset
    • Wideband ADC/DAC 16KHz Sampling
    • Narrowband Codec: G.711a/u, G.729AB, iLBC
    • Wideband Codec: G.722, Opus
    • Full-duplex Acoustic Echo Canceller (AEC)
    • Noise Reduction (NR)
    • Packet Loss Concealment (PLC)
    • Dynamic Adaptive Jitter Buffer
    • DTMF: In-band, Out-of-Band ā€“ DTMF-Relay (RFC2833) / SIP INFO
  • Network
    • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
    • IP Mode: IPv4
    • IP Configuration: Static / DHCP
    • Network Access Control: 802.1x
    • VPN: OpenVPN (Requires third-party app support)
    • VLAN, LLDP, CDP, QoS

More Information

MFRPartNum:
A320
Datasheet:
