i57A+i63 BUNDLE

Fanvil SIP Indoor Unit i57A + Video Door Phone i63 (BUNDLE)



Fanvil SIP Indoor Unit i57A + Video Door Phone i63 (Bundle)

Model: i57A

The Fanvil i57A indoor station features a 10.1-inch color touch screen with an intuitive UI. Based on Android 9.0 operating system, it can meet industry application customization needs and secondary development. Featuring powerful functionalities like remote door opening and real-time monitoring for security devices, i57A can serve as a management assistant for communities, villas and office buildings.


  • 10.1-inch (1280×800) capacitive color touch screen
  • Android 9.0 operating system, meeting the customization needs of industry applications and secondary development
  • Aluminum panel design, reliable and durable
  • Built-in cool lighting effects, which can be set as status indicators
  • Check real-time video of door phones with H.264 video codec and 1080P high resolution
  • HD voice speech quality with built-in 2W speaker and Acoustic Echo Canceller
  • Built-in Bluetooth 5.0 and 2.4GHz/5G WiFi
  • Support RS-485, 8 alarm input interfaces and 2 embedded relays
  • Integrated Micro USB interface and maximum 256GB capacity TF card slot
  • Support PoE, Support wall-mounted installation


Model: i63

Based on SIP and ONVIF protocols, i63 is a video door phone that integrates powerful functionalities of access control, intercom, and security protection. Featuring an aluminum alloy design and single speed dial touch button, i63 delivers a high-quality robust appearance. With high protection level IP66 and IK07, it is waterproof, dustproof and anti-collision in most outdoor environments. i63 allows users to make audio/video calls via a speed-dial button and a 2 Mega-pixel camera and achieve access control by different modes. With rich input and output interfaces, i63 is easy to link with other security devices and customize into various solutions in apartments, commercial buildings, communities and industrial parks.


  • With high protection level of IP66 and IK07, wide temperature range from -40℃ to 70℃, it can work perfectly in most outdoor environments
  • Support to open the door with RFID/IC cards, NFC, indoor switch, remote DTMF, Timed open door
  • Aluminum alloy design and 5 speed-dial buttons
  • Built in 2M pixels wide-angle camera: 120º(H), 60º(V) with infrared night-vision feature
  • Fitted with a tamper switch that detects unauthorized opening of the device itself
  • Compatible with SIP and ONVIF protocols
  • Built-in 3 short-in detect ports and 2 short-out control ports, can be integrated with induction loop antenna
  • Built-in maximum 128GB capacity TF card slot for image storage
  • HD voice speech quality with built-in 2.5W speaker and Acoustic Echo Canceller
