PRODUCT SPECIFICATIONS
The Fanvil i16S/i16SV SIP Intercom is designed for outdoor scenes with high reliability, HD Audio, and IP65/IK10 protection grade. It combines security, audio intercom and broadcasting functionalities and offer the best communication solution for users.
Highlights
- Built-in HD camera with infrared night vision, adopt H.264 codec (only i16SV)
- IP65 waterproof and dustproof.
- IK10 anti-collision with robust die-cast aluminum frame
- Anti-tamper- alarming as long as the cover is apart from the housing, and reporting to the control center at the same time
- HD voice speech quality with built-in 3W speaker and Acoustic Echo Canceller
- Audio line out port, expandable external active speaker.
- Built-in 2 short-in detect port and 2 short-out control port
- Support built-in TF card slot for data storage or audio offline broadcasting.
- Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.
Device dimensions
- 195x120x40 mm
Technical Description
- Generic
- 2 SIP lines
- Speed dial
- Oral announcement of the IP address(in English)
- MP3 broadcasting
- Support programmable DSS key
- Support mono active speaker
- Talkback recording output
- Switch signal input and output
- Support TF card
- PoE enabled
- Auto-answering
- Programmable DSS keys
- Through button or web page volume adjustment
- Network time synchronization
- Time Plan (task management)
- Incoming call multicast
- Dynamic multicast function
- HTTP API
- Action URL / Active URI
- Call Functions
- Call out / answer / reject
- Call waiting
- Intercom, Multicast
- Speed dial
- Anonymous call (Hide caller ID)
- Call parking/pick-up (depending on server)
- Audio
- Narrowband codec: G.711A/U, G.729A/B
- Wideband codec: G.722, Opus
- Full-duplex hands-free speakerphone with AEC
- DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
- Network
- Physical: 10/100 Mbps Ethernet
- IP mode:IPv4/IPv6/IPv4&IPv6
- IP configuration: Static IP / DHCP / PPPoE
- VPN: L2TP / OpenVPN
- Protocols
- SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN
- DHCP
- IPv6
- PPPoE
- L2TP
- OpenVPN
- SNTP
- FTP/TFTP
- HTTP/HTTPS
- TR-069
- Deployment & Management
- Auto-provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
- Web management portal
- Web-based packet dump
- Configuration export / import
- Firmware upgrade
- Syslog
- Physical Specifications
- 1 DSS key (support LED)
- RJ45 port x1: connect the network
- PoE enabled
- Line out port x1: connect the active speaker
- Out: adjustable by volume, max up to1.2Vpp.
- Port: terminal socket
- Recording output port x1: connect audio device
- Out: mixed output of local microphone voice andcall voicerecording
- Impedance: 15 Ohm
- Port: terminal socket
- Short circuit input and output port x2 (built-in relay)
- Relay: MAX DC30V / 2A, AC125V / 0.5A
- Active switching output: 12V/500mA DC(only 1 relaysupport)
- Port: terminal socket
- Tamper alarm switch: x1
- TF card slot x1: connect TF card
- DC port x1: DC power input
- DC power input: DC12V~24V/1A
- Port: 2 Pin terminal socket
- PoE level: Class 3
- Protection level: IP65 and IK10
- Housing material: aluminum alloy shell
- Installation: wall-mounted
- Working temperature: -30 °C ~ 60 °C
- Storage temperature: - 40 °C ~ 70 °C
- Working humidity: 10~95%
More Information
MFRPartNum:
i16S
