PRODUCT SPECIFICATIONS
Iuron N-M/TNC 50CM Coaxial Pigtail Cable
The Iuron N-M/TNC 50CM is a 50 cm coaxial cable assembly with an N-Male connector at one end and a TNC Male connector at the other. Listed with LMR400 cable, it provides a short RF interconnect where this connector combination is required.
Use this assembly when planning connections between RF equipment, antenna feed components or test interfaces. Confirm the complete assembly's electrical ratings against the intended application before installation.
Key Features
- N-Male to TNC Male connector configuration.
- 50 cm nominal length for short cable runs.
- LMR400 cable designation in the product listing.
Connector Selection
Check connector polarity as well as connector type. Standard TNC and reverse-polarity RP-TNC interfaces are different and should not be substituted for one another.
Ideal Applications
- Short RF jumper connections after application requirements are verified.
- Replacement of an existing assembly with matching connectors and confirmed electrical ratings.
Compatible Products
The listed connectors require corresponding standard N-Female and TNC Female interfaces. Matching connectors alone does not establish compatibility: verify system impedance, operating frequency, RF power, allowable cable loss and installation conditions.
Important: TNC is different from RP-TNC. Inspect the center contacts and confirm the equipment documentation before ordering. Do not select this assembly solely because the connector threads appear to fit.
Technical Specifications
General
- Brand: Iuron
- Listed Model / Part Number: N-M/TNC 50CM
- Product Type: RF coaxial pigtail cable assembly
Cable and Connectors
- Connector 1: N-Male
- Connector 2: TNC Male
- Listed Cable Type: LMR400
- Nominal Length: 50 cm / 0.5 m
