PRODUCT SPECIFICATIONS
Manhattan 102063 USB-C Power Delivery and USB-A Quick Charge Car Charger
The Manhattan 102063 is a dual-port vehicle charger for keeping compatible smartphones, tablets, and other USB-powered mobile devices charged while traveling. It combines one USB-C Power Delivery 3.0 port with one USB-A Quick Charge 3.0 port, allowing two devices to charge simultaneously.
Designed for use with a vehicle's 12V auxiliary power socket, this compact charger provides a convenient charging option for commuting, business travel, and road trips. Charging cables are sold separately.
Key Features
- Two charging ports for simultaneous device charging.
- One USB-C port with USB Power Delivery 3.0.
- One USB-A port with Quick Charge 3.0.
- Designed for vehicle auxiliary power sockets.
- Short-circuit, overvoltage, overcurrent, and overtemperature protection.
- Compact black plastic housing for convenient in-vehicle use.
USB-C Power Delivery
The USB-C port supports Power Delivery 3.0 for compatible devices. The charging mode depends on the power profiles supported by the charger, connected device, and cable. A USB-C connector alone does not establish fast-charging compatibility.
USB-A Quick Charge 3.0
The USB-A port supports Quick Charge 3.0 for devices that support this charging protocol. Devices using other charging technologies may charge at a lower rate. Use an appropriate charging cable for your device.
Vehicle Power Connection
Connect your charging cables to the USB ports and insert the charger into your vehicle's 12V auxiliary power socket, following the manufacturer's instructions.
Charging Protection
Integrated protection functions help safeguard the charger and connected devices against short circuits, excessive voltage, excessive current, and overheating.
Ideal Applications
- Charging compatible mobile devices during daily commutes.
- Keeping two devices connected to charging power during road trips.
- Charging compatible USB-C PD and USB-A QC 3.0 devices in a vehicle.
- Providing a compact charging option for business travel.
Compatible Products
Charging compatibility requires an appropriate cable and a device that supports the charger's available voltage and charging protocol. USB-C Power Delivery and USB-A Quick Charge 3.0 are separate charging technologies.
- Manhattan 394307 Charge & Sync USB-C to Lightning Cable, 1.8 m – MFi-certified USB-C-to-Lightning cable supporting up to 18 W Power Delivery charging. Connects the charger's USB-C PD port to compatible Lightning-equipped Apple devices. Actual charging power depends on the device and negotiated charging mode.
Important: The 394307 cable is for Lightning-equipped devices, not devices with a USB-C charging socket. It does not provide 24 W or 42 W charging. Charging cables are not included with the charger.
Power compatibility: Do not select this charger for a laptop, game console, or other device solely because it has a USB-C connector. The published output specifications conflict, and a required voltage or minimum power level may not be available. Confirm the supplied charger's label and the device manufacturer's charging requirements before use.
Technical Specifications
General
- Brand: Manhattan
- Model / MPN: 102063
- Product Type: Dual-port USB vehicle charger
- Manufacturer Product Name: Power Delivery Car Charger - 42 W
- Color: Black
Charging Interfaces
- Total USB Charging Ports: 2
- USB-C: 1 port with Power Delivery 3.0
- USB-A: 1 port with Quick Charge 3.0
- Simultaneous Charging: Supports two connected devices
- Charging Cables: Sold separately
Input Power
- Vehicle Connection: Auxiliary vehicle power socket
- Confirmed Installation Instruction: Connect to a 12V vehicle power socket
Output Power
- Advertised Product Rating: 42 W; conflicting detailed specifications require confirmation
- Advertised USB-C Output: Up to 24 W in the product heading and features; the detailed table instead specifies 18 W
- Advertised USB-A Output: Up to 18 W with QC 3.0
Protection Functions
- Short-Circuit Protection: Supported; auto-recovery listed
- Overvoltage Protection: Supported; auto-recovery listed
- Overcurrent Protection: Supported
- Overtemperature Protection: Supported
Physical Specifications
- Dimensions: 6.9 x 2.8 x 3.8 cm (2.72 x 1.1 x 1.5 inches)
- Weight: 70 g (2.5 oz.)
- Housing Material: Plastic
Environmental
- Operating Temperature: 0 to 30°C (32 to 86°F)
- Storage Temperature: -20 to 65°C (-4 to 149°F)
- Humidity: 10–90%, noncondensing
Manufacturer-Listed Standards and Compliance
- USB 2.0
- USB Power Delivery 3.0
- Quick Charge 3.0
- CE, RoHS, WEEE, ETL, FCC
Included Parts
- Manhattan 102063 car charger
- Quick instruction guide
