PRODUCT SPECIFICATIONS
Manhattan 102124 72W Power Delivery Charging Station
The Manhattan 102124 combines one USB-C Power Delivery 3.0 port with three USB-A charging ports. It provides up to 60W through USB-C and a separate 12W budget shared by the USB-A ports, supporting simultaneous charging from one compact station.
Designed for desks, home workspaces and travel, it can charge compatible USB-C laptops, tablets and phones alongside USB-A-powered devices. Power Delivery negotiates an appropriate supported charging profile with the connected USB-C device.
Key Features
- 72W maximum total output.
- One USB-C PD 3.0 port delivering up to 60W.
- Three USB-A ports sharing up to 12W at 5V.
- 100–240 VAC input for use with a suitable local power cord.
- Short-circuit, overvoltage, overcurrent and overtemperature protection.
- Compact black plastic housing.
USB-C Power Delivery
The USB-C output supports 5V, 9V, 12V, 15V and 20V profiles at up to 3A. Charging performance depends on the device's supported profiles, power requirements and charging cable.
Shared USB-A Charging
The three USB-A ports share a combined 5V/2.4A output. A single port can supply up to that limit when sufficient shared capacity is available; three connected devices do not each receive 12W.
Ideal Applications
- Charging a compatible USB-C laptop and smaller USB devices.
- Organizing phone and tablet charging at a desk.
- Providing a compact multi-device charging setup while traveling.
Compatible Products
USB-C devices must support USB Power Delivery and accept one of the charger's documented voltage profiles. Full-power USB-C charging requires a suitable cable rated for at least 60W/3A. USB-A devices must support 5V charging and remain within the shared 12W budget.
- Manhattan 394208 Charge & Sync USB-C to Lightning Cable – MFi-certified cable documented for use with Manhattan Power Delivery chargers, supporting up to 18W for compatible Lightning-equipped Apple devices.
Important: The USB-C port supplies a maximum of 60W, not 72W. A laptop requiring greater power may charge slowly or lose battery charge under load. The linked Lightning cable supports up to 18W and does not provide the charger's full 60W capability.
Technical Specifications
General
- Brand: Manhattan
- Model / MPN: 102124
- Product Type: AC-powered USB charging station
- Color: Black
- Maximum Total Output: 72W
Charging Interfaces
- USB-C: 1 x USB-C Power Delivery 3.0 output
- USB-A: 3 x USB-A charging outputs
- Total Charging Ports: 4
- USB-C Maximum Output: 60W
- USB-C Profiles: 5V/3A, 9V/3A, 12V/3A, 15V/3A and 20V/3A
- USB-A Output: 5V, up to 2.4A per port, subject to the shared limit
- Combined USB-A Limit: 12W / 2.4A shared across all three ports
AC Input
- Input Voltage: 100–240 VAC
- Frequency: 50–60 Hz
Protection
- Short-Circuit Protection: Automatic recovery
- Overvoltage Protection: Automatic recovery
- Additional Protection: Overcurrent and overtemperature
Physical Specifications
- Dimensions: 91 x 75 x 27.5 mm (3.58 x 2.95 x 1.08 in.)
- Weight: 0.22 kg (7.76 oz.)
- Housing: Plastic
Environmental
- Operating Temperature: 0°C to +30°C
- Storage Temperature: -20°C to +65°C
- Humidity: 10–90%, non-condensing
Manufacturer-Listed Standards and Compliance
- USB 2.0 and USB Power Delivery 3.0
- FCC, UL 62368, CE, RoHS and WEEE
Package Contents
- Manhattan 102124 Power Delivery Charging Station
- Power cord
- User Guide
