website@flyteccomputers.com

Intellinet

Part:
102186

Intellinet 102186 Qi-Certified Fast Wireless Charging Pad – 10 W, USB-C Input, Black

$14.95
Condition:
New

PRODUCT SPECIFICATIONS

Intellinet 102186 Qi-Certified Fast Wireless Charging Pad – 10 W

The Intellinet 102186 wireless charging pad offers a convenient way to recharge compatible Qi-enabled smartphones. Its compact, round design fits on a desk or bedside table, providing a dedicated charging surface without repeatedly connecting a cable to your phone.

Supporting 5 W, 7.5 W and 10 W charging modes, the pad accommodates different compatible devices. Available charging power depends on the receiving device and the connected USB power supply.

Key Features

  • Qi-certified wireless charging with output up to 10 W.
  • Supports 5 W, 7.5 W and 10 W charging modes for compatible devices.
  • USB-C power input.
  • LED indicators for charging-status monitoring.
  • Metal-object detection with output shutoff.
  • Short-circuit, overvoltage, overcurrent and overheating protection.
  • Charging through suitable nonmetallic phone cases up to 5 mm thick.
  • Includes a 1.5 m USB-C power cable.

Wireless Charging Performance

Place a compatible phone on the pad with its wireless charging area aligned over the charging surface. The maximum supported output is 10 W; actual charging power varies with the phone, power supply, alignment and operating conditions.

USB Power Requirements

A 5 V / 2 A USB supply supports 5 W wireless charging. For output up to 10 W, the product documentation specifies a suitable Quick Charge 2.0/3.0 charger or an 18 W USB Power Delivery charger. The pad's specified higher-power input is 9 V / 2 A.

The USB power adapter is sold separately. When using a USB-C Power Delivery supply, use a suitable USB-C-to-USB-C cable.

Phone Cases and Everyday Use

Suitable nonmetallic cases up to 5 mm thick can remain on the phone during charging. Remove metal cases, magnetic attachments, card holders and other accessories that interfere with wireless power transfer.

Ideal Applications

  • Everyday charging of compatible Qi-enabled smartphones.
  • Personal desktop charging with a compact charging pad.
  • Bedside charging without connecting a cable directly to the phone.

Compatible Products

The receiving device must support Qi wireless charging. A USB-C or Lightning connector alone does not establish wireless charging compatibility. Charging power depends on the device's supported wireless charging mode and the connected power supply.

  • Apple iPhone 8, 8 Plus, X, XR, XS and XS Max: Listed in the product documentation for the 7.5 W charging mode with an appropriate power supply.
  • Samsung Galaxy S7, S7 Edge, S8, S8+, S9, S9+ and S10: Listed for the 10 W fast-charging mode.
  • Samsung Galaxy Note8, Note9 and Note10: Listed for the 10 W fast-charging mode.
  • 102124 72 W USB Charging Station with USB-C Power Delivery – Its USB-C PD output includes a 9 V / 3 A profile, satisfying the pad's documented 9 V / 2 A supply requirement. Connect through the USB-C PD port using a suitable USB-C-to-USB-C cable.

Important: Maximum output is 10 W, and not every compatible phone charges at that rate. The 102124 charging station's USB-A ports provide 5 V power and do not provide the pad's 9 V fast-charging input. Compatibility with proprietary smartwatch charging systems or additional phone models must be verified separately.

Technical Specifications

General

  • Manufacturer / Brand: Intellinet
  • Model / MPN: 102186
  • Product Type: Fast wireless charging pad
  • Wireless Charging Standard: Qi
  • Color: Black
  • Indicators: LED charging-status indicators

Power and Charging

  • Power Input: USB-C
  • Specified Input Profiles: 5 V DC / 2 A or 9 V DC / 2 A
  • Wireless Charging Modes: 5 W, 7.5 W and 10 W maximum
  • Output with 5 V / 2 A Input: 5 W
  • Output with 9 V / 2 A Input: Up to 10 W
  • Supply for Higher-Power Charging: Suitable Quick Charge 2.0/3.0 charger or 18 W USB Power Delivery charger
  • USB Power Adapter: Sold separately

Protection Features

  • Metal Detection: Output shutoff when interfering metal is detected
  • Short-Circuit Protection: Automatic recovery
  • Overvoltage Protection: Automatic recovery
  • Overcurrent Protection: Supported
  • Overtemperature Protection: Supported

Physical Specifications

  • Dimensions: 90 x 90 x 10.6 mm (3.54 x 3.54 x 0.42 in.)
  • Net Weight: 59 g (2.08 oz.)
  • Housing Material: ABS and PC
  • Supported Phone Case Thickness: Up to 5 mm with suitable nonmetallic cases
  • Included Cable Length: 1.5 m (5 ft.)

Environmental

  • Operating Temperature: 0–30°C (32–86°F)
  • Storage Temperature: -20–65°C (-4–149°F)
  • Humidity: 10–90%, non-condensing
  • Installation Environment: Dry indoor locations

Listed Standards and Compliance

  • Qi
  • CE
  • FCC
  • RoHS
  • WEEE

Included Parts

  • Intellinet 102186 wireless charging pad
  • 1.5 m USB-C power cable
  • Quick instruction guide

Download Intellinet 102186 10 W Qi Wireless Charging Pad Datasheet (PDF)

More Information

MFRPartNum:
102186
Datasheet:
