PRODUCT SPECIFICATIONS
Intellinet 513555 Cat5e 24-Port UTP Patch Panel
The Intellinet 513555 provides a central termination point for copper network cabling. Its 24 RJ45 ports help organize connections and simplify changes to equipment assignments in offices, wiring closets and structured cabling installations.
The black panel fits a standard 19-inch rack and occupies 1U of rack space. It supports Ethernet, Fast Ethernet and Gigabit Ethernet applications using Cat5e unshielded twisted-pair cabling.
Key Features
- 24 RJ45 ports with rear punch-down terminations.
- Cat5e UTP construction with gold-plated jack contacts.
- Accepts 22–26 AWG solid or stranded wire.
- Compatible with 110 and Krone punch-down tools.
- 180° cable-entry punch-down blocks.
Installation and Termination
Follow the T568A or T568B color coding when positioning conductors, then terminate them with the appropriate punch-down tool. Secure and organize the cable runs to support a serviceable installation.
Ideal Applications
- Office and commercial structured cabling.
- Rack-mounted network distribution points.
- Organized patching between permanent cable runs and network equipment.
Compatible Products
The rear terminals accept Cat5e UTP cabling with 22–26 AWG solid or stranded conductors. The front ports accept corresponding RJ45 patch cable plugs. Installation requires a suitable 110 or Krone punch-down tool and a standard 19-inch rack mounting position.
- Intellinet 318952 Cat5e UTP RJ45 Patch Cable, 1 m, Red – compatible for front-panel patching to network equipment; its RJ45 male connectors mate with the panel's RJ45 ports.
Important: This is an unshielded Cat5e punch-down panel. Select a shielded or higher-category panel when the installation requires those capabilities. The rear connections require conductor termination rather than plug-in patch cables.
Technical Specifications
General
- Brand: Intellinet Network Solutions
- Model / MPN: 513555
- Alphanumeric Part Number: IPP-19C5E24-1U
- Product Type: Passive network patch panel
- Color: Black
Connections and Cabling
- Front Ports: 24 x RJ45
- Category / Shielding: Cat5e / UTP
- Rear Termination: 180° entry punch-down blocks
- Supported Conductors: 22–26 AWG, solid or stranded
- Tool Compatibility: 110 / Krone
- Wiring Schemes: T568A / T568B
- Jack Contacts: Gold-plated
Network Applications
- Ethernet: IEEE 802.3, 10BASE-T
- Fast Ethernet: IEEE 802.3u, 100BASE-TX
- Gigabit Ethernet: IEEE 802.3ab, 1000BASE-T
Physical and Environmental
- Mounting: 19-inch rack, 1U
- Dimensions: 482 x 43 x 63 mm (W x H x D)
- Net Weight: 528 g
- Operating Temperature: -40 to 80°C
Certifications
- UL
- CE
- RoHS
Included Parts
- Cat5e patch panel
- Four mounting screws
- Quick start guide
