PRODUCT SPECIFICATIONS
Mikrotik CRS112-8P-4S-IN 8 Gigabit Port PoE Smart Switch 4 SFP Cages with 802.3af/at PoE/PoE+ and Passive PoE Autosensing
CRS112-8P-4S-IN is an eight Gigabit RJ45 port PoE switch, that offers different power output options: autosensing 802.3af/at PoE/PoE+ and Passive PoE, and four SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.
CRS112-8P-4S-IN is equipped with 12 independent switching ports. 28 V 3.4 A power supply is already included in the box. There is secondary DC jack on the back of the enclosure that supports 48-57 V power supply (not included, can be purchased separately - product codes 48POW (1.46A 70W) and 48V2A96W (2A 96W)). CRS112-8P-4S-IN can power 802.3af/at devices if 48-57 V DC input is used (unit will automatically detect and provide correct power to devices). Max current is 1 A per port if input voltage is 18-28 V, 450 mA if 48-57 V. Total limit is 2.8A@24V and 1.4A@48-57V. PoE-Out is passed over mode B 4,5 (+) and 7,8 (-) pins.
Technical Description
- Specifications
- Product code: CRS112-8P-4S-IN
- Architecture: MIPSBE
- CPU: QCA8511
- CPU core count: 1
- CPU nominal frequency: 400 MHz
- Switch chip model: QCA8511
- Dimensions: 200 x 142 x 44 mm
- RouterOS license: 5
- Operating System: RouterOS
- Size of RAM: 128 MB
- Storage size: 16 MB
- Storage type: FLASH
- MTBF: Approximately 200'000 hours at 25C
- Tested ambient temperature: -20°C to 60°C
- Powering
- Number of DC inputs: 2 (DC jack)
- DC jack input Voltage: 18-28 V / 48-57 V
- Max power consumption: 160 W
- Max power consumption without attachments: 10 W
- Cooling type: Passive
- PoE-out
- PoE-out ports: Ether1-Ether8
- PoE out: 802.3af/at
- Max out per port output (input 18-30 V): 1 A
- Max out per port output (input 30-57 V): 450 mA
- Max total out (A): 2.8A (18V-28V) & 1.4A (48V-57V) A
- Ethernet
- 10/100/1000 Ethernet ports: 8
- Number of 1G Ethernet ports with PoE-out: 8
- Fiber
- SFP ports: 4
- Peripherals
- Serial console port: RJ45
- Other
- PCB temperature monitor: Yes
- Certification & Approvals
- Certification: CE, EAC, ROHS
- IP: IP20
