PRODUCT SPECIFICATIONS
If you are working with substantial amount of data – like providing Internet access or maintaining a huge data center – this is the perfect upgrade for your setup. CRS326-24S+2Q+RM is our first product with 40 Gbps QSFP+ ports for remarkably fast and stable fiber connection.
Overall it has two 40 Gbps QSFP+ ports and twenty four 10 Gbps SFP+ ports, which provides total nonblocking throughput of 320 Gbps and switching capacity of 640 Gbps with forwarding rate of 252 Mpps with most common packets.
CRS326-24S+2Q+RM is easy to manage – it has a full size USB port for configuration and dual power supply for redundancy – no unexpected downtime, your clients and colleagues will be thankful!
You can choose between our legendary feature-packed RouterOS for booting or a simpler, but still powerful SwOS. If you would like the ability to use routing and other Layer 3 features in your CRS, use RouterOS.
Technical Description
- Specifications
- Product code: CRS326-24S+2Q+RM
- Architecture: MIPSBE
- CPU: QCA9531
- CPU core count: 1
- CPU nominal frequency: 650 MHz
- Dimensions: 443 x 200 x 44 mm
- RouterOS license: 5
- Operating System: RouterOS or SwitchOS
- Size of RAM: 64 MB
- Storage size: 16 MB
- Storage type: FLASH
- MTBF: Approximately 200'000 hours at 25C
- Tested ambient temperature: -20°C to 60°C
- Powering
- Number of AC inputs: 2
- AC input range: 100-240
- Max power consumption: 69 W
- Max power consumption without attachments: 42 W
- FAN count: 3
- Ethernet
- 10/100 Ethernet ports: 1
- Fiber
- SFP+ ports: 24
- Number of 40G QSFP+ ports: 2
- Peripherals
- Serial console port: RJ45
- Number of USB ports: 1
- USB Power Reset: Yes
- USB slot type: USB type A
- Max USB current (A): 1
- Certification & Approvals
- Certification: CE, EAC, ROHS
- IP: IP20
