PRODUCT SPECIFICATIONS
L009 boasts a robust dual-core ARM CPU, offering significant enhancements in routing, firewall rules, and IPsec encryption, leveraging the latest Linux Kernel features. Its modern architecture supports custom container projects via a full-sized USB port, enabling diverse applications like Pi-hole adblock or LTE modem integration. With up to 4x speed improvement over RB2011, Gigabit Ethernet ports, PoE capabilities, and an SFP cage supporting 2.5 Gigabit connectivity, L009 excels in versatility and performance. Enhanced with Generation 6 wireless, it ensures up to 90% higher speed and superior stability. The innovative enclosure facilitates efficient rackmount deployment, allowing multiple routers in a single space. Whether optimizing server rooms or maximizing networking efficiency, L009 sets a new standard in functionality and space management, making it the ultimate upgrade choice.
Technical Description
- Specifications
- Product code: L009UiGS-2HaxD-IN
- Architecture: ARM
- CPU: IPQ-5018
- CPU core count: 2
- CPU nominal frequency: 800 MHz
- Switch chip model: 88E6190
- RouterOS license: 5
- Operating System: RouterOS v7
- Size of RAM: 512 MB
- Storage size: 128 MB
- Storage type: NAND
- MTBF: Approximately 200'000 hours at 25C
- Tested ambient temperature: -40°C to 70°C
- Wireless capabilities
- Wireless 2.4 GHz Max data rate: 574 Mbit/s
- Wireless 2.4 GHz number of chains: 2
- Wireless 2.4 GHz standards: 802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz: 4
- Wireless 2.4 GHz chip model: IPQ-5018
- Wireless 2.4 GHz generation: Wi-Fi 6
- WiFi speed: AX600
- Ethernet
- 10/100/1000 Ethernet ports: 8
- Number of 1G Ethernet ports with PoE-out: 1
- Fiber
- SFP ports: 1 (2.5G supported)
- Peripherals
- Serial console port: RJ45
- Number of USB ports: 1
- USB Power Reset: Yes
- USB slot type: USB 3.0 type A
- Max USB current (A): 1.5
- Powering
- Number of DC inputs: 2 (DC jack, PoE-IN)
- DC jack input Voltage: 24-56 V
- Max power consumption: 42 W
- Max power consumption without attachments: 14 W
- Cooling type: Passive
- PoE in: 802.3af/at
- PoE in input Voltage: 24-56 V
- PoE-out
- PoE-out ports: Ether8
- PoE out: Passive PoE
- Max out per port output (input 18-30 V): 1 A
- Max out per port output (input 30-57 V): 450 mA
- Max total out (A): 1.0 A
- Certification & Approvals
- Certification: CE, FCC, IC, EAC, ROHS
- IP: 20
