Part:
R11e-LR9

Mikrotik Concentrator Gateway card for LoRa Technology in mini PCIe form Factor

$89.00

PRODUCT SPECIFICATIONS

MikroTik is bringing you new, powerful products for LoRa® for the fraction of the cost you would expect.

R11e-LR9 is a new concentrator Gateway card for LoRa® technology in mini PCIe form factor based on Semtech SX1301 chipset. It enables LoRa® connectivity for any MikroTik product that has mPCIe slot with connected USB lines.

With the support of 8 different channels, Listen Before Talk (LBT) and spectral scan features this product will astound you with its enticing price point.

Operates in 902-928 MHz frequency (used in United States, Canada, Mexico, Australia, Brazil, many countries in Asia etc.)

Technical Description

  • Product code    R11e-LR9
  • MTBF    Approximately 100'000 hours at 25C
  • Tested ambient temperature    -40°C to 60°C

Powering

  • Max power consumption    2 W

Certification & Approvals

  • Certification    FCC, IC

Interface

  • Mini-PCIe

Supported class

  • A and C

Frequency

  • 902-928 MHz (AU915-928, US902-928, AS923, KR920-923)

RF Output power

  • 902-928 MHz 23 dBm

Receive max sensitivity

  • -137 dB @ SF12

Range

  • Up to 15 km in rural environment and up to 2 km in urban environment when using MikroTik LoRa® 6.5 dBi antenna kit (not included)


More Information

MFRPartNum:
R11e-LR9
Datasheet:
