PRODUCT SPECIFICATIONS
The MikroTik RB750r2 hEX Lite is a compact and affordable 5-port Ethernet router designed for small office and home networks. Powered by an 850 MHz CPU and 64 MB RAM, the RB750r2 runs MikroTik’s powerful RouterOS Level 4, offering advanced features such as routing, firewall, VLAN, VPN, and QoS management in a small and energy-efficient device.
With five Fast Ethernet ports and Passive PoE-in support, the MikroTik RB750r2 is ideal for wired network management, basic routing, and home lab environments where flexibility and RouterOS functionality are required.
Key Features
- 5 x Fast Ethernet ports (10/100 Mbps)
- 850 MHz single-core CPU
- 64 MB RAM and 16 MB Flash storage
- RouterOS Level 4 license included
- Passive PoE-in support
- Low power consumption (approx. 2W)
- Compact SOHO router design
Ideal Applications
- Small office and home networks
- Home lab routing setups
- Entry-level MikroTik RouterOS deployments
- Edge routing and firewall configurations
- Low-cost MPLS and VLAN testing environments
Technical Description
- Specifications
- Product code: RB750UPr2
- Architecture: MIPSBE
- CPU: QCA9531
- CPU core count: 1
- CPU nominal frequency: 650 MHz
- Switch chip model: QCA9531
- Dimensions: 113x89x28mm
- RouterOS license: 4
- Operating System: RouterOS
- Size of RAM: 64 MB
- Storage size: 16 MB
- Storage type: FLASH
- MTBF: Approximately 100'000 hours at 25C
- Tested ambient temperature: -40°C to 70°C
- Powering
- Number of DC inputs: 2 (PoE-IN, DC jack)
- DC jack input Voltage: 8-30 V
- Max power consumption: 51 W
- Max power consumption without attachments: 3 W
- Cooling type: Passive
- PoE in: Passive PoE
- PoE in input Voltage: 8-30 V
- PoE-out
- PoE-out ports: Ether2-Ether5
- PoE out: Passive PoE
- Max out per port output (input 18-30 V): 1 A
- Max total out (A): 2 A
- Ethernet
- 10/100 Ethernet ports: 5
- Peripherals
- Number of USB ports: 1
- USB Power Reset: Yes
- USB slot type: USB type A
- Max USB current (A): 1
- Other
- Current Monitor: Yes
- PCB temperature monitor: Yes
- Voltage Monitor: Yes
- Certification & Approvals
- Certification: CE, EAC, ROHS
- IP: IP20
More Information
MFRPartNum:
RB750r2
Datasheet:
