PRODUCT SPECIFICATIONS
Mikrotik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G kit
The KNOT LR8G is a compact, out-of-the-box gateway for LoRa®-based networks, designed to bring affordable, reliable connectivity to even the most remote or infrastructure-light environments. It supports LTE CAT-M1 and NB2, Bluetooth 5.2, 2.4 GHz Wi-Fi, GPS, and Ethernet with PoE, making it a flexible centrepiece for any IoT deployment.
Key Features
- LoRa ® 868MHz
- CAT-M/NB technology
- 2.4 GHz wireless
- RS485/Modbus
- 2x 100 Mbps Ethernet ports
- PoE-in & PoE-out
- GNSS
- GPIO
- Bluetooth
- Product code: RB924iR-2nD-BT5&BG770A&R11e-LR8G
- CPU QCA9531: 650 MHz
- CPU architecture: MIPSBE
- Size of RAM: 64 MB
- RAM type: DDR2
- Storage: 128 MB, NAND
- Number of 100M Ethernet ports: 2
- USB port: 1 microUSB type AB
- Wireless: 2.4 GHz 802.11b/g/n
- Wireless interface model: QCA9531
- Antenna gain: 1.5 dBi
- Antenna beam width: 360°
- GNSS interface model: MT3337V
- GNSS standard: GPS
- Antenna connector SMA: female
- LoRa band: 868MHz
- Bluetooth version: 5.2
- IoT modem: BG770A
- Cat NB type: Cat NB2
- Cat NB band: B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66
- Cat M type: Cat M1
- Cat M band: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66
- Operating system: RouterOS v7, License level 4
- Operating temperature: -40°C to +70°
More Information
MFRPartNum:
RB924iR-2nD-BT5&BG770A&R11e-LR8G
