Mikrotik

Part:
RDS2216-2XG-4S+4XS-2XQ

MikroTik RDS2216-2XG-4S+4XS-2XQ ROSE Data Server with 20x U.2 Bays, 25G & 100G Networking

$1,699.99
$1,950.00
Condition:
New

PRODUCT SPECIFICATIONS

MikroTik RDS2216-2XG-4S+4XS-2XQ ROSE Data Server

The MikroTik RDS2216-2XG-4S+4XS-2XQ is a high-performance ROSE Data Server that combines enterprise storage, high-speed networking, routing, switching, and container workloads in a single rackmount platform.

Powered by a 16-core 2.0 GHz ARM64 processor with 32 GB ECC DDR4 RAM, the RDS2216 is designed for demanding storage, virtualization, container, networking, and data-intensive applications.

The system provides 20 U.2 PCIe Gen3 SSD bays for high-speed storage, along with 2 M.2 SATA slots for additional storage. This makes it suitable for large storage pools, caching, backup systems, edge computing, media workflows, and enterprise data services.

High-speed network connectivity includes 4 x 25G SFP28, 2 x 100G QSFP28, 4 x 10G SFP+, and 2 x 1/2.5/5/10G RJ45 Ethernet ports, allowing the RDS2216 to integrate directly into modern data center, enterprise, ISP, and high-capacity network environments.

Key Features

  • ROSE Data Server platform
  • 20 x U.2 PCIe Gen3 SSD bays
  • 2 x M.2 SATA storage slots
  • 16-core ARM64 CPU at 2.0 GHz
  • 32 GB ECC DDR4 RAM
  • 4 x 25G SFP28 ports
  • 2 x 100G QSFP28 ports
  • 4 x 10G SFP+ ports
  • 2 x 1/2.5/5/10G RJ45 Ethernet ports
  • 1 x dedicated Gigabit Ethernet port
  • Marvell Prestera 98DX4310 switch chip
  • Layer 3 Hardware Offloading support
  • RouterOS v7 Special ROSE Edition
  • RouterOS Level 6 license
  • Container support
  • Dual redundant hot-swappable power supplies
  • USB 3.0 and USB 2.0 ports
  • RJ45 serial console

20-Bay U.2 NVMe Storage

The RDS2216 includes twenty PCIe Gen3 drive trays designed for U.2 SSDs up to 7 mm in height. This provides substantial high-speed storage capacity for data-intensive workloads while allowing administrators to build flexible storage pools and services directly on RouterOS.

32 GB ECC Memory and 16-Core ARM64 CPU

A 16-core AL73400 ARM64 processor running at 2.0 GHz and 32 GB of ECC DDR4 memory provide the compute resources required for storage services, networking, containers, routing, monitoring, and other advanced workloads.

25G and 100G High-Speed Networking

Four SFP28 interfaces provide up to 25 Gbps each, while two QSFP28 ports support up to 100 Gbps. Four additional 10G SFP+ ports and two multi-gigabit RJ45 interfaces provide flexible connectivity for servers, switches, storage networks, and data center infrastructure.

Layer 3 Hardware Offloading

The integrated Marvell Prestera 98DX4310 switch chip supports hardware-assisted Layer 3 routing, allowing compatible traffic to be processed directly by the switching hardware for significantly higher throughput than CPU-only routing.

RouterOS v7 Special ROSE Edition

The RDS2216 runs a special ROSE edition of RouterOS v7, combining MikroTik networking capabilities with storage and container functionality. Administrators can use routing, firewall, VLAN, VPN, monitoring, scripting, container workloads, and storage features from a single platform.

Redundant Power and Serviceable Cooling

Dual hot-swappable AC power supplies improve uptime and allow the system to remain operational if one power source fails. The server also uses active cooling designed for sustained enterprise workloads.

Ideal Applications

  • Enterprise storage systems
  • Data center edge infrastructure
  • High-speed backup and archive systems
  • Container and application hosting
  • ISP and service-provider infrastructure
  • High-capacity network storage
  • Media and content workflows
  • RouterOS-based storage and networking labs

Technical Specifications

  • Product code: RDS2216-2XG-4S+4XS-2XQ
  • Architecture: ARM 64bit
  • CPU: AL73400
  • CPU core count: 16
  • CPU nominal frequency: 2000 MHz
  • Switch chip model: 98DX4310
  • RouterOS license: 6
  • Operating System: RouterOS v7 (Special ROSE edition)
  • Size of RAM: 32 GB
  • Storage size: 128 MB
  • Storage type: NAND
  • MTBF: Approximately 200'000 hours at 25C
  • Tested ambient temperature: -20°C to 50°C
  • IPsec hardware acceleration: Yes
  • Powering:
    • Number of AC inputs: 2
    • AC input range: 100-240
    • Frequency (Hz): 50-60
    • Max power consumption: 286 W
    • Max power consumption without attachments: 105 W
    • Cooling type: 10 fans
  • Ethernet:
    • 10/100/1000 Ethernet ports: 1
    • Number of 1G/2.5G/5G/10G Ethernet ports: 2
  • Fiber:
    • SFP+ ports: 4
    • Number of 25G SFP28 ports: 4
    • Number of 100G QSFP28 ports: 2
  • Peripherals:
    • Serial console port: RJ45
    • Number of USB ports: 2
    • USB Power Reset: Yes
    • USB slot type: USB 3.0 type A
    • Max USB current (A): 1
    • Number of M.2 slots: 2
  • Other:
    • CPU temperature monitor: Yes
    • PCB temperature monitor: Yes
    • Voltage Monitor: Yes
    • Mode button: Yes
  • Certification & Approvals:
    • Certification: CE, EAC, ROHS
    • IP: 20
  • Included parts:
    • IEC cord
    • IEC cord
    • K-90 fastening set
    • Rackmount ear (ROSE)
    • Small rear support ears (ROSE)
    • Long rear Rackmount support ears (ROSE)

MikroTik RDS2216 Frequently Asked Questions

Is PCIe 3.0 sufficient for the RDS2216 SSDs?

Each U.2 drive uses two PCIe 3.0 lanes. The disk subsystem connects to the CPU through 16 lanes. Performance varies by workload and configuration.

Do two 100G ports guarantee 200 Gbps storage throughput?

No. The interfaces also serve networking workloads. Storage throughput depends on processing, drives, protocols, and configuration.

Can I use M.2 SSDs in the RDS2216?

Yes. MikroTik supports M.2 adapters. Check drive and adapter compatibility before purchasing.

What redundancy features does the RDS2216 offer?

It includes dual hot-swappable power supplies and supports designs using RAID, NVMe-TCP, VRRP, and bonding. Availability depends on system design and configuration.

Does the RDS2216 support Layer 3 hardware offloading?

Yes. Its 98DX4310 switch chip supports L3HW offloading, subject to RouterOS support conditions.

Why is the RDS2216 green?

According to MikroTik, the color represents the product's focus on energy efficiency.

More Information

MFRPartNum:
RDS2216-2XG-4S+4XS-2XQ
