PRODUCT SPECIFICATIONS
Mikrotik S53UG+5HaxD2HaxD-TC&R11e-LTE7 Chateau LTE7 ax
Your favorite high-performance home and office LTE router just got a major upgrade. Chateau LTE7 ax keeps the same powerful hardware, sleek design, and Wi-Fi 6 performance – but now features an LTE Category 7 modem, expanded frequency support, and a significantly lower price than the previous LTE6 ax version.
Key Features
- Powerful 1.8 GHz Quad-core ARM CPU
- Strong Dual-band, Dual-chain radio
- Fast and responsive LTE Cat7 modem
- Container support
- 4x Gigabit ethernet ports
- 1 GB of RAM
- Specifications:
- Architecture: ARM 64bit
- CPU: IPQ-6010
- CPU core count: 4
- CPU nominal frequency: auto MHz
- CPU Threads count: 4
- Switch chip model: IPQ-6010
- RouterOS license: 4
- Operating System: RouterOS v7
- Size of RAM: 1 GB
- Storage size: 128 MB
- Storage type: NAND
- MTBF: Approximately 200'000 hours at 25C
- Tested ambient temperature: -40°C to 70°C
- Powering:
- Number of DC inputs: 1 (DC jack)
- DC jack input Voltage: 12-28 V
- Max power consumption: 21.5 W
- Max power consumption without attachments: 15.5 W
- Cooling type: Passive
- Mobile:
- 3G Category: R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
- 3G bands:
- 1 (2100 MHz)
- 5 (850 MHz)
- 8 (900 MHz)
- 3 (1800 MHz)
- LTE Category: 7 (DL: 300 Mbps; UL: 100 Mbps)
- MIMO DL: 2x2
- MIMO UL: 1x1
- LTE FDD bands:
- 1 (2100 MHz)
- 3 (1800 MHz)
- 5 (850 MHz)
- 7 (2600 MHz)
- 8 (900 MHz)
- 20 (800 MHz)
- 28 (700 MHz)
- 32 (1500 MHz)
- LTE TDD bands:
- 38 (2600 MHz)
- 40 (2300 MHz)
- 41 (2500 MHz)
- TAC: 35312597
- Wireless specifications:
- Wireless 2.4 GHz Max data rate: 574 Mbit/s
- Wireless 2.4 GHz Number of chains: 2
- Wireless 2.4 GHz standards: 802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz: 3
- Wireless 2.4 GHz chip model: QCN-5022
- Wireless 2.4 GHz generation: Wi-Fi 6
- Wireless 5 GHz Max data rate: 1200 Mbit/s
- Wireless 5 GHz Number of chains: 2
- Wireless 5 GHz standards: 802.11a/n/ac/ax
- Antenna gain dBi for 5 GHz: 6
- Wireless 5 GHz chip model: QCN-5052
- Wireless 5 GHz generation: Wi-Fi 6
- Ethernet:
- 10/100/1000 Ethernet ports: 4
- Number of 2.5G Ethernet ports: 1
- Peripherals:
- Number of SIM slots: 1 Modem (Micro SIM)
- Number of USB ports: 1
- USB Power Reset: Yes
- USB slot type: USB type A
- Max USB current (A): 1
- Other:
- CPU temperature monitor: Yes
- PCB temperature monitor: Yes
- Voltage Monitor: Yes
- Mode button: Yes
- Certification & Approvals:
- Certification: CE, EAC, ROHS
- IP: 20
- Included parts:
- 24V 1.2A power adapter
- UTP Flat Cable (1.5m)
More Information
MFRPartNum:
S53UG+5HaxD2HaxD-TC&R11e-LTE7
