Mimosa Networks

Part:
100-00017

Mimosa A5 4.9–6.4GHz Unparalled Access Point-to-Multipoint Access Point

Sale
$598.50
$600.00
Condition:
New
Mimosa A5 4.9–6.4GHz Unparalled Access Point-to-Multipoint Access Point
PRODUCT SPECIFICATIONS More Information

PRODUCT SPECIFICATIONS

The Mimosa A5 access point delivers cutting-edge multipoint technology for service providers to affordably deliver the industry’s first scalable, gigabit, wireless broadband network.

Highlights

Fiber Speed Access

  • Capable of delivering the speed business users and consumers need at a fraction of the cost of delivering fiber-to-the-premise.

Network-Wide Cloud Control

  • Mimosa Cloud makes deployment a breeze, interacting with devices network-wide to proactively assist the A5 to optimize network and subscriber experience for the best performance and capacity management.

Working Above the Noise

  • Advanced auto-gain control techniques automatically squelch out underlying interference with only 10 dB of operating margin required to deliver incredible client performance.

Compact and Fast

  • With up to 1.0 Gbps of total capacity, the A5 is the industry’s fastest multipoint solution in a tiny form factor, making suburban rooftop or urban installation a fast, easy and discrete solution.

Network Scalability Perfected

  • Unique integrated, high-precision GPS Sync technology allows every deployed device to be collaboratively synchronized across the network, allowing easy channel reuse to save spectrum network-wide.

Dimensions

  • 314 mm (12.36”) height x 142.44 mm (5.61”) width

Weight

  • 1.75 kg (3.85 lbs)

Technical Specifications

  • Features
    • Gigabit Ethernet: 10/100/1000-BASE-T
    • Synchronization: GPS+GLONASS allows for network-wide sync and interference avoidance
    • Collocation: 1PPS GPS Tx/Rx synchronization for same tower collocation and channel reuse
    • Network Processing: Advanced AP control for capacity and subscriber management
    • Management Services:
      • Mimosa cloud monitoring and management SNMPv2 & Syslog legacy monitoring
      • HTTPS; HTML 5-based Web UI; 2.4 GHz 802.11b/g/n radio for local management access
    • Smart Spectrum Management:
      • Active scan monitors/logs ongoing RF interference across channels (no service impact)
      • Dynamic auto-optimization of channel and bandwidth use
    • Security:
      • WPA2 PSK & Enterprise 802.1x
      • Radius provisioning, COA, DM
      • 128-bit AES with hardware acceleration
    • VLANs:
      • Per subscriber VLAN
      • Q-in-Q, triple tagging
      • Management VLAN
    • QoS: Supports 4 pre-configured QoS levels
    • GPS Location: GNSS1 (GPS + GLONASS)
    • Traffic Shaping: Per CPE UL/DL commit and maximum rate shaping
    • Access Control List: Permit, deny, and remark layer 2 and layer 3 traffic flows
  • Performance
    • Max Throughput: Up to 1.0 Gbps IP (1.7 Gbps PHY)
    • Client Capacity:
      • 100 clients (WiFi Interop)
      • 44 clients (SRS)
    • Wireless Protocols:
      • WiFi Interop
      • Spectrum Reuse Synchronization (SRS)
  • Radio
    • MIMO & Modulation: 4x4:4 MIMO OFDM up to 256-QAM
    • Bandwidth**:
      • 20/40/80 MHz channels tunable in 5 MHz increments for GPS Sync
      • Tunable to standard WiFi channels for WiFi Interop
        • **4.9 GHz uses 20 MHz channel widths (US only, regulations vary by region)
    • Frequency Range:
      • 4900–6400 MHz*
        • * restricted by country of operation (US/FCC 5600–5650 support)
        • *A5/A5c extended frequency, above 6.2 GHz, requires P/N 100-000xx-01
    • Max Output Power: 30 dBm
    • Sensitivity ( MCS 0 ):
      • -87 dBm @ 80 MHz
      • -90 dBm @ 40 MHz
      • -93 dBm @ 20 MHz
  • Antenna
    • Gain: 14 dBi
    • Beamwidth ( 3 dB ): 70° azimuth
    • Electrical Downtilt: None
    • Front-to-Back Ratio: >30 dB
    • Cross-Polar Isolation: >20 dB or greater
    • Polarization: Circular, 4 alternating panels
  • Environmental
    • Outdoor Ingress Protection Rating: IP67
    • Operating Temperature: -40°C to +55°C (-40°F to 131°F)
    • Operating Humidity: 5 to 100% condensing
    • Operating Altitude: 4,420 m (14,500’) maximum
    • Shock & Vibration: ETS 300-019-2-4 class 4M5
  • Physical
    • Enclosure Characteristics: Outdoor UV-stabilized engineered polymer
    • Wind Survivability: 200 km/h (125 mph)
    • Wind Loading:
      • 7.72 kg @ 160 km/h
      • 17.03 lbs @ 100 mph
    • Mounting: Dual-pole strap feed points integrated into metal base with integrated curvature for contact with mounting poles
  • Power
    • Max Power Consumption: 25 W
    • System Power Method: 802.3 at compliant
    • System Lightning & ESD Protection: 6 kV
    • PoE Power Supply: 802.3at and Passive POE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection
  • Regulatory + Compliance
    • Approvals: FCC Part 15.407 and Part 90Y, IC RSS210 and RSS111, CE, ETSI 301 893/302 502
    • RoHS Compliance: Yes
    • Safety: UL/EC/EN/ 60950-1 + CSA-22.2

More Information

MFRPartNum:
A5-14
Datasheet:
Click here
