PRODUCT SPECIFICATIONS

With the fastest client speeds and great access point capacity, along with local and network-wide spectrum reuse, the connectorized Mimosa A5c delivers the highest possible scale for any unlicensed fixed wireless network. The A5c is well suited for long-range pole and tower multipoint applications, access point collocation (GPS Sync) and Municipal and Rural Licensed Public Safety multipoint (4.9 GHz).

Increased Capacity at Each Site
- With integrated, high-precision GPS Sync technology, new A5c sectors can easily be added at existing Mimosa A5 and B5 sites and reuse the same channel.
- This saves valuable, scarce unlicensed spectrum resources when new A5c devices are installed “back-to-back” on the same tower or pole.
Network Scalability Perfected
- Every deployed device is collaboratively synchronized across the network. This allows easy channel reuse to save valuable spectrum network wide.
- Connected to the Mimosa Cloud, deployment of the A5c is incredibly simple with network spectrum use and performance optimized across all of your deployed devices.
Ultra-High Client Capacity
- TDMA techniques provide significant improvements when scaling the number of clients.
- By dynamically allocating upstream timeslots upon client request, network scale, spectrum efficiency and access point utilization are optimized to the highest degree possible.
Fiber Speeds
- With client speeds capable of 500+ Mbps and access point capacity up to 1.0 Gbps (IP), the A5c delivers the speeds consumers and business users demand at a fraction of the cost of delivering fiber-to-the-premises.
Add Subscribers with Ease
- Install, aim and go! We’ve eliminated manual installation and pre-provisioning complexity, so you can focus on adding subscribers quickly.

Dimensions

300 mm (11.81”) x 151 mm (5.94”) x 85 mm (3.35”)

Weight

1.75 kg (3.86 lbs)

Technical Description

Performance
- Max Throughput: Up to 1.0 Gbps IP (1.7 Gbps PHY)
- Client Capacity:
  - 100 clients (WiFi Interop)
  - 44 clients (SRS)
- Wireless Protocols: WiFi Interop, Spectrum Reuse Synchronization (SRS)
Radio
- MIMO & Modulation: 4x4:4 MIMO OFDM up to 256-QAM
- Bandwidth**:
  - 20/40/80 MHz channels
    - Tunable in 5 MHz increments for GPS Sync
    - Tunable to standard WiFi channels for WiFi Interop
      - **4.9 GHz uses 20 MHz channel widths
- Frequency Range:
  - GPS Sync: 4900–6400 MHz
  - WiFi Interop: 5170–5835 MHz
    - Restricted by country of operation (‘new’ US/FCC 5600–5650 support)
- Max Output Power: 30 dBm
- Sensitivity (MCS 0):
  - -87 dBm @ 80 MHz
  - -90 dBm @ 40 MHz
  - -93 dBm @ 20 MHz
Power
- Max Power Consumption: 25 W
- System Power Method: 802.3at compliant
- PoE Power Supply: Passive POE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection
Physical
- Enclosure Characteristics: Outdoor UV-stabilized engineered polymer with integrated mounting panel
- Mounting: Dual-pole strap mount and slip on mount for comparable antenna
- Connector Type: Female Type N (x4)
Environmental
- Outdoor Ingress Protection Rating: IP67
- Operating Temperature: -40°C to +55°C (-40°F to 131°F)
- Operating Humidity: 5 to 100% condensing
- Operating Altitude: 4,420 m (14,500’) max
- Shock & Vibration: ETS 300-019-2-4 class 4M5
Features
- Gigabit Ethernet: 10/100/1000-BASE-T
- Synchronization: GPS+GLONASS allows for network-wide sync and interference avoidance
- Collocation: 1PPS GPS Tx/Rx synchronization for same tower collocation and channel reuse
- Network Processing: Advanced AP control for capacity and subscriber management
- Management Services:
  - Mimosa Cloud monitoring and management
  - SNMPv2 & Syslog legacy monitoring
  - HTTPS, HTML 5-based Web UI
    - (2.4 GHz WiFi management module no longer available as of December 2020)
- Smart Spectrum Management: Active scan monitors/logs ongoing RF interference across channels (no service impact); Dynamic autooptimization of channel and bandwidth use
- Security:
  - WPA2 PSK & Enterprise 802.1x
  - Radius provisioning, COA, DM; 128-bit AES with hardware acceleration
- VLANs: Per subscriber VLAN; Q-in-Q, triple tagging; Management VLAN
- QoS: Supports 4 pre-configured QoS levels
- GPS Location: GNSS1 (GPS + GLONASS)
- Traffic Shaping: Per CPE UL/DL commit and maximum rate shaping
- Access Control List: Permit, Deny and Remark Layer 2 and Layer 3 traffic flows
Regulatory and Compliance
- Approvals: FCC Part 15.407 and Part 90Y, IC RSS210, CE, ETSI 301 893/302 502
- RoHS Compliance: Yes
- Safety: UL/EC/EN/ 60950-1 + CSA-22.2
